| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4R210-06 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Manual Control Direct Acting Type |
|---|---|---|---|
| Port Size: | 1/8'' | Valve Type: | 5 Way 2 Position |
| Pressure Range: | 0 To 1.0MPa (0 To 145 Psi) | Max Pressure Resistance: | 1.5 MPa (215 Psi) |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| High Light: | Push Pull Air Valve,5/2 Push Pull Valve,Airtac 4R210-06 |
||
4R210-06 Airtac Type Manual Push Pull Air Control Valve 5/2 Way
The 4R210-06 is a manual pneumatic directional valve with a 5 way operation & 5 ports (P = Pressure, A = Outlet, EA = Exhaust for port A). 5 way, 2 position valves are generally used to fully extend a single acting (spring return) cylinder, or in applications with similar operation.
Features:
* Manual operation, smooth actuation,and exact and reliable orientation;
* Sliding column structure has good tightness and light weight and is easy to install and dismount;
* Internal hole adopts special processing technology which has little attrition friction, long service life;
* No need to add oil for lubrication;
* Panel-mounting makes it convenient to install and apply.
Technical Data of 4R series Push Pull Valve:
| Model | 4R110-06 | 4R210-06 | 4R210-08 | 4R310-08 | 4R310-10 |
| Fluid | Air (to be filtered by 40μm filter element) | ||||
| Operating | Manual control direct acting type | ||||
| Port Size | 1/8'' | 1/4'' | 3/8'' | ||
| Orifice Size (Cv) |
10.2mm² (Cv=0.6) |
4L210-08: 17.0mm² (Cv=1.0) |
4L310-10: 28.0mm² (Cv=1.65) |
||
| Valve Type | 5/2 Way | ||||
| Pressure Range | 0 to 1.0MPa (0 to 145 psi) | ||||
| Proof Pressure | 1.5 MPa (215 psi) | ||||
| Temperature | -20 to +70℃ | ||||
| Body Material | Aluminum Alloy | ||||
Ordering Code of 4R series Push Pull Valve:
Dimension of 4R series Push Pull Valve:
Inner Structure of 4R series Push Pull Valve:
Production Video of BRANDO Pneumatic Valves:
More Pneumatic Products for you to choose:
| 2/2 Way Pneumatic Valves | 3/2 Way Pneumatic Valves | 5/2 Way Pneumatic Valves | 5/3 Way Pneumatic Valves |
|
|
|
|
| Namur Solenoid Valves | FRL Unit | Pneumatic Cylinders | Silencers and Fittings |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
