| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4R110-06 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Manual Control Direct Acting Type |
|---|---|---|---|
| Port Size: | 1/8'' | Valve Type: | 5 Way 2 Position |
| Pressure Range: | 0 To 1.0MPa (0 To 145 Psi) | Max Pressure Resistance: | 1.5 MPa (215 Psi) |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| High Light: | Push Pull Valve 5 Way,Push Pull Air Control Valve,Airtac 4R110-06 |
||
4R110-06 Airtac Type Hand Push Pull Air Control Valve 5 Way
Features of Push Pull Air Valve:
1. A manual push and pull button allows the user to change the direction of flow.
2. Intuitive design ensures simple interface for even the most complex applications.
3. Accurate spool cylinder ensures push or pull button interface achieves flow through the desired ports.
4. Can be panel mounted with the button's shaft or through three pre-drilled mounting holes in the valve's body.
5. Maximum operating pressure of 215 PSI.
Technical Data of 4R series Push Pull Valve:
| Model | 4R110-06 | 4R210-06 | 4R210-08 | 4R310-08 | 4R310-10 |
| Fluid | Air (to be filtered by 40μm filter element) | ||||
| Operating | Manual control direct acting type | ||||
| Port Size | 1/8'' | 1/4'' | 3/8'' | ||
| Orifice Size (Cv) |
10.2mm² (Cv=0.6) |
4L210-08: 17.0mm² (Cv=1.0) |
4L310-10: 28.0mm² (Cv=1.65) |
||
| Valve Type | 5/2 Way | ||||
| Pressure Range | 0 to 1.0MPa (0 to 145 psi) | ||||
| Proof Pressure | 1.5 MPa (215 psi) | ||||
| Temperature | -20 to +70℃ | ||||
| Body Material | Aluminum Alloy | ||||
Ordering Code of 4R series Push Pull Valve:
Dimension of 4R110-06 Push Pull Valve:
Inner Structure of 4R series Push Pull Valve:
Production Video of BRANDO Pneumatic Valves:
