G353A041 3/4'' Inch Right Angle Air Reverse Remote Pilot Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	G353A041

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Type:	Right Angle Type Diaphragm Valve	Power:	Pneumatic
Media:	Air	Port Size:	3/4'' Inch
Structure:	Diaphragm	Body Material:	Aluminum Alloy
Diaphragm Material:	NBR(Common), FKM(Available)	Number Of Diaphragm:	1
Pressure:	0.1 To 0.8MPa	Temperature:	-25 To +80℃
High Light:	G353A041 Remote Pilot Valve , Air Reverse Remote Pilot Valve , ASCO Type G353A041

G353A041 3/4'' Inch Right Angle Air Reverse Remote Pilot Valve

This is G353A041 ASCO Type Pulse Jet Valve, 3/4'' inlet and outlet threaded port size, Remote Pilot, NBR or TPE diaphragm for you to choose, 24V DC, 110V AC, 220V AC voltages for you to choose, other voltages can be customized.

353 Series Pulse Jet Valve:
1. Threaded Pulse Jet Valve: SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051
2. Remote Pilot Pulse Jet Valve: G353A041, G353A042, G353A045
3. Immersion Pulse Jet Valve: SCXE353.060

Technical Data of ASCO Pulse Jet Valve:

Port Size	Remote Pilot Connection	Office Size	Operating Pressure Differential (Bar)		Model Number	Diaphragm Material
G	φB	(mm)	Min.	Max.	Aluminium	NBR/Viton
G	φB	(mm)	Min.	Max.	Aluminium
3/4''	1/8''	24	0.35	8.5	G353A041
1''	1/8''	27	0.35	8.5	G353A042
1 1/2''	1/8''	52	0.35	8.5	G353A045

Main Dimension:

G353A041 3/4'' Inch Right Angle Air Reverse Remote Pilot Valve 0

353 Series Pulse Jet Valve For Dust Collector System:

Right Angle Valve	3/4''	1''	1 1/2''	2''	2 1/2''
	SCG353A043	SCG353A044	SCG353A047	SCG353A050	SCG353A051
Submerged Valve	3''
	SCEX353.060
Remote Pilot Valve	3/4''		1''	1 1/2''
	G353A041		G353A042	G353A045

FEATURES
• The diaphragm pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation
• The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust tcollector service applications
• Integral compression fittings for fast, easy, secure installation
• Valves can be supplied according to ATEX Directive 2014/34/EU for non-electrical equipment
• The valves satisfy all relevant EC directives
