Home ProductsDiaphragm Repair Kit

1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set

1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set

  • 1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set
  • 1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set
1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: J40
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Name: Diaphragm Repair Kit Applicable Valves: JICI 40, JICR 40, JISI 40, JISR 40, JIFI 40, JIFR 40
Diaphragm Material: NBR (Buna) Mounting Hole Size: φ8.5mm
Diaphragm Outer Diameter: φ109.0mm Hole Center Distance: φ103.5mm
Seat Material: NBR (Buna) Seat OD: φ58.5mm
Seat ID: φ34.0mm Bleed Hole: 1
Packaging: Individual Plastic Bag Sealed
High Light:

1-1/2" Diaphragm Set

,

Pulse Jet Valve Diaphragm Set

,

Joil Type 1.5'' Diaphragm

1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set



This is repair kit NBR diaphragm, used in Joil 1 1/2" JICI 40, JICR 40, JISI 40, JISR 40, JIFI 40, JIFR 40 diaphragm pulse valves. One set of diaphragm kit includes one buna seat buna diaphragm and one small stainless steel spring. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.



Pulse valves are mainly used in the environmental protection and dust removal industry. They are controlled by solenoid or pneumatic pilot valves and can instantly open and close high-pressure gas sources to generate pulse valves. They are also commonly known as electromagnetic pulse valves or pneumatic pulse valves.

use:

The electromagnetic pulse valve (also known as the diaphragm valve) is the compressed air "switch" of the pulse bag filter cleaning and blowing system. Under the control of the output signal of the pulse controller, the filter bag is sprayed row by row (room) to clean the dust to keep the resistance of the dust collector within the set range to ensure the processing capacity and dust collection efficiency of the dust collector.

The Z-type pulse valve is a right-angle valve with an angle of 90° between the inlet and outlet. It is suitable for the installation link between the air bag and the blowing pipe. It has smooth air flow and can provide dust-cleaning air pulses that meet the requirements.

The Y-type pulse valve is a submerged valve (also called an embedded valve), which is directly installed on the air bag and has better flow characteristics. The pressure loss has been reduced, which is suitable for working occasions with low air source pressure.



YouTube video of Diaphragm Repair Kit For 1 1/2'' Joil Pulse Valve:



Main dimension of JICI/JICR 40 JISI/JISR 40 JIFI/JIFR 40 Diaphragm:

1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set 0



Details display of 1.5'' JICI/JICR JISI/JISR JIFI/JIFR Valve Diaphragm:

1-1/2" JICI40 JICR40 JISI40 JISR40 JIFI40 JIFR40 Pulse Jet Valve Diaphragm Set 1



Available Models of Diaphragm Valve Repair Kits For Joil Pulse Valves:

Ordering Code
Type
Quatity
Suitable valve
Material
J20
3/4''
1
JICI 20, JICR 20,
JISI 20, JISR 20
Nitrile/Buna
J25
1''
1
JICI 25, JICR 25,
JISI 25, JISR 25
J40 & JTY-X
1 1/2''
2
JICI 40, JICR 40,
JISI 40, JISR 40,
JIFI 40, JIFR 40
J50 & JTY-X
2''
2
JISI 50, JISR 50,
JIFI 50, JIFR 50
J76 & JTY-X
2 1/2''
2
JISI 65, JISR 65,
JIFI 65, JIFR 65
J89 & JTY-X
3''
2
JISI 80, JISR 80,
JIHI 80, JIHR 80
J102 & JTY-X
4''
2
JIHI 100, JIHR 100



Tips: The related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!

Contact Details
Ningbo Brando Hardware Co., Ltd

Contact Person: Brandon

Tel: +8613454729544

Send your inquiry directly to us
