JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit

JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit

  • JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit
  • JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit
JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: J25
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Name: Diaphragm Repair Kit Applicable Valves: JICI 25, JICR 25, JISI 25, JISR 25
Diaphragm Material: NBR (Nitrile) Mounting Hole Size: φ8.5mm
Diaphragm Outer Diameter: φ82.0mm Hole Center Distance: φ82.0mm
Seat Material: Nylon Seat OD: φ47.0mm
Seat ID: φ28.0mm Bleed Hole: 1
Packaging: Individual Plastic Bag Sealed
High Light:

JICI25 Diaphragm Repair Kit

,

Nitrile Diaphragm Repair Kit

,

Joil Korea 1'' Diaphragm

JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit



This is a diaphragm repair kit that helps you repair and replace Joil valves sized 1''. The repair kit comes with 1 nitrile main diaphragm and 1 stainless steel spring to help replace JICI 25, JICR 25, JISI 25, JISR 25 pulse valves. Brando is a dust collector diaphragm valve & diaphragm repair kits manufacturer for replace almost popular brands, suck like Goyen, ASCO, Mecair, Norgern, Joil, Turbo and so on. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible.



The high temperature resistance of fluorine rubber is the same as that of silicone rubber, which can be said to be the best among elastomers.
26-41 fluorine rubber can be used for a long time at 250°C and short-term use at 300°C; 246 fluorine rubber has better heat resistance than 26-41.
The physical properties of 26-41 after air heat aging at 300℃×100 hours are equivalent to those of type 246 after air aging at 300℃×100 hours. The elongation at break can be maintained at about 100%, and the hardness is 90 to 95 degrees. .
Type 246 maintains good elasticity after aging in hot air at 350°C for 16 hours, and maintains good elasticity after aging in hot air at 400°C for 110 minutes. After aging in hot air at 400°C for 110 minutes, it contains spray carbon black, thermal black or carbon fiber. The elongation of the rubber compound increases by about 1/2 to 1/3, and the strength decreases by about 1/2, while still maintaining good elasticity.
The 23-11 type fluorine rubber can be used for a long time at 200°C and for a short time at 250°C.



YouTube video of Diaphragm Repair Kit For 1 Inch Joil Pulse Valve:



Main dimension of Diaphragm For JICI 25 JICR 25 JISI 25 JISR 25:

JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit 0



Details display of 1'' JICI/JICR JISI/JISR Pulse Valve Diaphragm:

JICI25 JICR25 JISI25 JISR25 1'' Inch Nitrile Diaphragm Repair Kit 1



Available Models of Diaphragm Valve Repair Kits For Joil Pulse Valves:

Ordering Code
Type
Quatity
Suitable valve
Material
J20
3/4''
1
JICI 20, JICR 20,
JISI 20, JISR 20
Nitrile/Buna
J25
1''
1
JICI 25, JICR 25,
JISI 25, JISR 25
J40 & JTY-X
1 1/2''
2
JICI 40, JICR 40,
JISI 40, JISR 40,
JIFI 40, JIFR 40
J50 & JTY-X
2''
2
JISI 50, JISR 50,
JIFI 50, JIFR 50
J76 & JTY-X
2 1/2''
2
JISI 65, JISR 65,
JIFI 65, JIFR 65
J89 & JTY-X
3''
2
JISI 80, JISR 80,
JIHI 80, JIHR 80
J102 & JTY-X
4''
2
JIHI 100, JIHR 100



Tips: The related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12
