M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit

M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit

  • M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit
  • M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit
M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: AE25
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Diaphragm Repair Kit Suitable Valves: AE1825B, AE2825R
Suitable Valve Port Size: 1'' Diaphragm Material: TPE
Diaphragm Outer Diameter: φ77.0mm Seat OD: φ45.5mm
Seat ID: φ16.0mm Bleed Hole: 1
Spring: Without Packaging: Individual Plastic Bag Sealed
High Light:

M/D25 Diaphragm Repair Kit

,

TPE Diaphragm Repair Kit

,

AUTEL Type M/D25

M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit



The TPE diaphragm kit is the heart of the AUTEL 1'' AE1825B, AE2825R pulse valve, the material advantage are high temperature resistance, fatigue resistance, high strength, high resilience. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions. The characteristics of AUTEL pulse valve compare favourably with other products on the market are the result of an innovative housing design based on advanced air technology and the application of TPE diaphragm technology. The TPE diaphragm is the key component in diaphragm pulse jet valves designed to provide short pressure decay times and high kv-values. Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.



(1) It can be processed by general thermoplastic molding machines, such as injection molding, extrusion molding, blow molding, compression molding, and transfer molding.
(2) It can be vulcanized by a rubber injection molding machine, and the time can be shortened from about 20 minutes to less than 1 minute.
(3) It can be molded and vulcanized with an extruder, with fast extrusion speed and short vulcanization time.
(4) The waste materials generated during the production process (escape burrs, extrusion of waste rubber) and the final waste products can be directly returned for reuse.
(5) The used TPE products can be reused after simple regeneration, reducing environmental pollution and expanding resource regeneration sources.
(6) There is no need for vulcanization, which saves energy. Take the energy consumption of high-pressure hose production as an example: rubber is 188MJ/kg, TPE is 144MJ/kg, which can save energy by more than 25%.
(7) The self-reinforcing property is large, and the formula is greatly simplified, so that the influence of the compounding agent on the polymer is greatly reduced, and the quality and performance are easier to grasp.
(8) To open up new ways for the rubber industry and expand the application fields of rubber products.





YouTube video of TPE Diaphragm Repair Kit For AUTEL Pulse Valve:



Main dimension of Diaphragm Repair Kit For 1'' AUTEL Pulse Valve:

M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit 0



Details of Diaphragm For AUTEL 1'' AE1825B AE2825R Pulse Valve:

M/D25 AE1822B AE1825R Pulse Jet Valve TPE Diaphragm Repair Kit 1



Available Models of Diaphragm Valve Repair Kits For AUTEL Pulse Valves:

Ordering Code
Fitted Valve Code
Valve Port Size
Material
AE20
AE1818B, AE2818B
3/4''
TPE
AE25
AE1825B, AE2825R
1''
TPE
AE40
AE1440B, AE1440R
AE2440B, AE2440R
1-1/2''
TPE
AE50-60
AE1450B, AE2450R,
AE1460B, AE2460R
2'', 2-1/2''
TPE
AE75
AE1475I12
3''
TPE
Tips: FKM+PTFE also available


Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12



Diaphragm Features:


1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility



5. EPDM, Viton all available.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
