| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4M320-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Valve Type: | 5 Way 2 Position | Port Size: | In=3/8'', Out=1/4'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8 MPa | Max Pressure Resistance: | 1.2 MPa |
| Body Material: | Aluminum Alloy | Max Frequency: | 4 Cycle/ Second |
| Acting: | Internal Pilot | Temperature Range: | -20 To +70℃ |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | ||
| High Light: | Solenoid Valve Namur 5/2,Solenoid Namur Valves,Airtac 4M320-10 |
||
4M320-10 Airtac Type Solenoid Pneumatic Valve Namur 5/2 Way
NAMUR valves can be used in a variety of pneumatic and hydraulic systems to control actuators, larger industrial valves or fluid power motors. They come in a range of sizes, including compact in-line versions which can be used individually or in a manifold. These provide high flow rates for their small size. The standard interfaces of NAMUR valves and direct mounting make them simpler and faster to install than integrated pneumatic solenoids, and therefore help to reduce installation costs. There is also less damage to pipelines, and more room for installers to refit the other components.
Technical Data of 4M Series Namur Solenoid Valve:
| Model No |
4M110-M5 4M120-M5 |
4M110-06 4M120-06 |
4M210-06 4M220-06 |
4M210-08 4M220-08 |
4M310-08 4M320-08 |
4M310-10 4M320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||||
| Port Size | In=Out=M5 | In=Out=1/8'' | In=Out=1/8'' | In=1/4'', Out=1/8'' | In=Out=1/4'' | In=3/8'', Out=1/4'' |
| Orifice Size |
5.5mm² (Cv=0.31) |
12.0mm² (Cv=0.67) |
14.0mm² (Cv=0.78) |
16.0mm² (Cv=0.89) |
25.0mm² (Cv=1.40) |
30.0mm² (Cv=1.67) |
| Valve Type | 5 Way 2 Position | |||||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||||
| Proof Pressure | 1.5MPa (215PSI) | |||||
| Temperature (℃) | -20 to +70 | |||||
| Body Material | Aluminum Alloy | |||||
| Max. Frequency | 5 Cycle / Second | 4 Cycle / Second | ||||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||||
| Coil Protection Class | IP65 | |||||
| Activating Time | 0.05 second and below | |||||
Dimension of 4A320-10 Namur Solenoid Valve:
Production Video of BRANDO Pneumatic Valves:
