| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4M210-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Valve Type: | 5 Way 2 Position | Port Size: | In=1/4'', Out=1/8'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8 MPa | Max Pressure Resistance: | 1.2 MPa |
| Body Material: | Aluminum Alloy | Max Frequency: | 5 Cycle/ Second |
| Acting: | Internal Pilot | Temperature Range: | -20 To +70℃ |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | ||
| High Light: | Namur Interface Solenoid Valve,Namur Solenoid Valve 5/2,Airtac 4M210-08 |
||
4M210-08 Airtac Type Namur Interface Solenoid Valve 5/2 Way
A NAMUR solenoid valve is directly mounted to pneumatic actuator inlet/outlet ports.
The function of a NAMUR solenoid valve is to control media flow: the valve itself is controlled by an electric solenoid, which opens or closes the valve, by controlling the amount of air thru a pilot to the pneumatic actuator. The solenoid and actuator work in tandem to control flow speed, flow amount, and flow direction. Likewise, the valve is operated in either the normally closed, or normally open position.
Solenoid valves are available in several configurations, including 3 way and 4 way. They are commonly applied for operating double acting rack and pinion actuators.
Technical Data of 4M Series Namur Solenoid Valve:
| Model No |
4M110-M5 4M120-M5 |
4M110-06 4M120-06 |
4M210-06 4M220-06 |
4M210-08 4M220-08 |
4M310-08 4M320-08 |
4M310-10 4M320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||||
| Port Size | In=Out=M5 | In=Out=1/8'' | In=Out=1/8'' | In=1/4'', Out=1/8'' | In=Out=1/4'' | In=3/8'', Out=1/4'' |
| Orifice Size |
5.5mm² (Cv=0.31) |
12.0mm² (Cv=0.67) |
14.0mm² (Cv=0.78) |
16.0mm² (Cv=0.89) |
25.0mm² (Cv=1.40) |
30.0mm² (Cv=1.67) |
| Valve Type | 5 Way 2 Position | |||||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||||
| Proof Pressure | 1.5MPa (215PSI) | |||||
| Temperature (℃) | -20 to +70 | |||||
| Body Material | Aluminum Alloy | |||||
| Max. Frequency | 5 Cycle / Second | 4 Cycle / Second | ||||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||||
| Coil Protection Class | IP65 | |||||
| Activating Time | 0.05 second and below | |||||
Dimension of 4A210-08 Namur Solenoid Valve:
