| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3A210-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Valve Type: | 3 Way 2 Position | Port Size: | In=Out=1/4'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8 MPa | Max Pressure Resistance: | 1.5 MPa |
| Body Material: | Aluminum Alloy | Max Frequency: | 5 Cycle/ Second |
| Acting: | Exterior Control | Temperature Range: | -20 To +70℃ |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | ||
| High Light: | Pneumatic Single Pilot Valve,3/2 Way Air Pilot Valve,Airtac 3A210-08 |
||
3A210-08 Airtac Type Single Air Pilot Pneumatic Valve 3/2 Way
Air pilot operated valves control single-acting or double-acting cylinders by directing or blocking airflow in a pneumatic circuit. These air operated valves come with single pilot or double pilot actuators and anywhere from two to five ports connected to a passage. Pilot operated pneumatic valves are often used in areas where electrical signals create a fire hazard, or when air pressure control is preferred.
Select from air piloted valves with single-pilot spring return or double-pilot 2-position operation. Double-pilot models are also available in a 3-position center-closed configuration.
Technical Data of 3A200 Series Pneumatic Air Pilot Valve:
Dimension of 3A210-08 Pneumatic Air Pilot Valve:
Production Video of BRANDO Pneumatic Valves:
