VF5220 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	VF5220

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	$3 to $ 5 per pc
Packaging Details:	Individual box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Valve Type:	5 Way 2 Position	Port Size:	In=Out=Exhaust=3/8''
Pressure Range:	0.15 To 0.8MPa	Max Pressure Resistance:	1.2 MPa
Body Material:	Aluminum Alloy	Wiring Form:	Lead Wire Or DIN43650 Connector
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:	Pneumatic Solenoid Valve 5/2 Way , Pneumatic Solenoid Valve 24V , SMC VF5220

VF5220 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24V 220V

Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.

BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.

Technial Data of VF & VZ Series Pneumatic Solenoid Valves:

Model	VF3130	VF33(4/5)30	VF5120	VF53(4/5)50	VZ5120	VZ53(4/5)50
Model	VF3230	VF33(4/5)30	VF5220	VF53(4/5)50	VZ5220	VZ53(4/5)50
Valve Type	5/2 way	5/3 way	5/2 way	5/3 way	5/2 way	5/3 way
Orifice Size	16mm² (Cv=0.89)	12mm² (Cv=0.67)	25mm² (Cv=1.4)	18mm² (Cv=1)	12mm² (Cv=0.67)	9mm² (Cv=0.50)
Fluid	Air (to be filtered by 40 μm filter element)
Operating Pressure	0.15 to 0.8 MPa
Proof Pressure	1.2 MPa
Body Material	Aluminum Alloy
Max Frequency	5 cycle / sec
Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Wire Form	Lead Wire or DIN43650 Connector

Dimension of VF5220 Pneumatic Solenoid Valve:

VF5220 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24V 220V 0
