| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | C113443, C113444 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union L/C, T/T, PayPal, Western Union |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Diaphragm | Ordering Code: | C113443, C113444, C113-443, C113-444 |
|---|---|---|---|
| Diaphragm Material: | TPE, NBR, VITON | 1 Set: | 1x Diaphragm, 1x Spring |
| Fitted Pulse Valve Port Size: | 3/4'', 1'' | Fitted Pulse Valve Model: | SCG353A043, SCG353A044, G353A041, G353A042 |
| High Light: | ASCO C113443 Membrane,ASCO C113444 Membrane,ASCO Pulse Valve Membrane |
||
Membrane For ASCO Pulse Valve SCG353A043 SCG353A044 G353A041 G353A042
C113443, C113444, C113-443, C113-444 Diaphragm (Membrane) for ASCO pulse valve SCG353A043, SCG353A044, G353A041, G353A042; TPE, NBR, Viton are all available; Pulse valves are the "switch" for compressed air in the dust clean blowing system of the pulse bag filter. It is used to control the release of air pulses in the cleaning cycle. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the solenoid valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.
Ordering Number of Diaphragm For ASCO Pulse Valve:
|
Valve Port Size
|
Pulse Valve Model
|
Diaphragm Model
|
Diaphragm Material
(FKM is also available)
|
|
3/4''
|
SCG353A043
|
C113444
|
TPE (White), NBR (Black)
|
|
1''
|
SCG353A044
|
||
|
3/4''
|
SCG353-052
|
||
|
1''
|
SCG353-053
|
||
|
3/4''
|
SGG353A043
|
||
|
1''
|
SGG353A044
|
||
|
3/4''
|
SGG353-052
|
||
|
1''
|
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
|
C113827
|
NBR
|
|
SGG353A065
|
|||
|
2''
|
SCG353A050
|
C113685, C113686
|
NBR
|
|
2 1/2''
|
SCG353A051
|
||
|
3''
|
SCXE353.060
|
C123432, C123433
|
NBR
|
|
SCG353D060
|
|||
|
3/4''
|
G3530A41
|
C113443
|
NBR
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR
|
|
G353-066
|
|||
|
1 1/2''
|
G353A046
|
C113826
|
NBR
|
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
NBR
|
|
2 1/2''
|
G353A049
|
Main Dimension of C113443, C113444 Diaphragm:
Product Video of C113443, C113444 Membrane:
Pictures of Pulse Valve Diaphragm Production:
More Related Products For you to choose:
|
|
|
|
| Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
|
|
|
|
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
