14.6mm Hole DIN 43650A ZB09 Espresso Machine Lucifer Solenoid Coil

14.6mm Hole DIN 43650A ZB09 Espresso Machine Lucifer Solenoid Coil

Solenoid valves dispense liquids and are for use in gas shutoff, vacuum holding, and tank draining. Solenoid valve coils convert electrical energy into linear motion to control the opening and closing of solenoid valves.

481865A4 Parker Type Solenoid Valve Spare Parts.

Part Number: 439515

Insulation Class:F

Voltage: 48/50

Power: 8W

The use of high pressure gases became a necessityin the new technologies developed during the last years.The control of these fluids can be done through the solenoid valves high pressure applications(maximum 50 bar).
The life expectancy of several millions of cycles, with response time of few milliseconds, allows the use of these valves on intensive applications and on high technology machines, as the plastic bottle blowing machines, or the laser cutting machines.

Technical data:

Dimension:

Details:

DIN 43650A Connector:

Parker Type Lucifer Valve Suitable for a wide variety of coffee machine :

BEZZERA Coffee machine ELLISSE
BRASILIA Coffee machine CENTURY, PORTOFINO
CONTI Coffee machine CLUB, TWINSTAR2, XEOS2
ESSIKA Coffee machine SK2, SSK2
FAEMA Coffee machine COMPACT, DUEA, E61, E91, EXPRESS
FIORENZATO C.S. Coffee machine MURANO
PAVONI Coffee machine BART
RANCILIO Coffee machine EPOCA
RENEKA Coffee machine LC, VIVA, VIVA S, XL-PALLAS
SAN MARCO Coffee machine EUROPA95, NS85

The ambient temperature which the coils can withstand depends on the following factors:
1) Coil wattage.
2) Coil overheating due to continuous service energisation. May be checked by resistance change test (∆T).
3) Service of the coil (continuous service or intermittent service). Coil in continuous or intermittent use.
4) Temperature of the fluid which is shut off by the solenoid valve. Ambient conditions which may affect heat dissipation.
5) Conditions of dissipation of the environment in which the solenoid valve is installed.

All the coils, as mentioned previously, are designed for continuous service, therefore the maximum ambient temperature value (bearing in mind the influence of the fluid temperature) is 50°C (for windings in class F) and +80°C (for windings in class H).
