CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve

CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve

  • CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve
  • CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve
CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: CA45DD
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Dresser Nut Diaphragm Valve Power: Solenoid
Media: Air Port Size: 1-1/2''Inch
Structure: Diaphragm Body Material: Aluminum Alloy
Diaphragm Material: NBR(Common), FKM(Available) Number Of Diaphragm: 2
Pressure: 0.1 To 0.8MPa Temperature: -25 To +80℃
High Light:

DD Series Pulse Jet Valve

,

Integral Pilot Pulse Jet Valve

,

Goyen Type CA45DD

CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve



Pulse Jet Valve play an important role in dust collector. A dust collector is a system used to enhance the quality of air released from industrial and commercial processes by collecting dust and other impurities from air or gas. Designed to handle high-volume dust loads, a dust collector system consists of a blower, dust filter, a filter-cleaning system, and a dust receptacle or dust removal system. It is distinguished from air purifiers, which use disposable filters to remove dust.



Maintenance Kits:

Model Nitrile FKM Low Temperature–60°C (–76°F) MIN. Includes
CA/RCA25DD K4502 K4503 K4522 Diaphragm kits include main and secondary diaphragms and all spring
K4510 K4511 NA 2 dresser seals, 2 dresser nuts, 2 seal retainers
K0380 K0384 NA o-ring, armature assembly, armature spring, ferrule



Technical Data of Goyen Pulse Jet Valve:

Model
CA20DD
CA25DD
CA45DD
Nominal Size
20
25
45
Port size
mm
20
25
40
in
3/4
1
1 1/2
Number of Diaphragms
1
1
2
Flow
Kv
12
20
44
Cv
14
23
51
Pressure (Psi)
5 to 125
5 to 125
5 to 125
Temperature℃
NBR
-40 to 82
-40 to 82
-40 to 82
FKM
-29 to 232
-29 to 232
-29 to 232


Main Dimension:

CA45DD DD Series 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve 0



CA RCA Series Pulse Jet Valve For Dust Collector System:



Thread Valve
1/2''
3/4''
1''
1.5''
1.5''
2''
2.5''
3''
CA15T
CA20T
CA25T
CA35T
(Single Diaphragm)
CA45T
(Double Diaphragm)
CA50T
CA62T
CA76T
Dresser Nut Valve
1''
1.5''
CA25DD
CA45DD
Flanged Valve
1.5'' Inlet
2'' Inlet
CA25FS
CA45FS
Immersion Valve
φ60 Outlet
φ75 Outlet
φ89 Outlet
φ86 Outlet
CA50MM
CA62MM
CA89MM
Remote Pilot Valve
1/8''
1''
1.5''
2''
RCA3D2
RCA25DD
RCA45T
RCA50T



Main Part of CA45DD Pulse Valve:

Solenoid Coil

Solenoid is the generic term for a coil of wire used as an electromagnet. It also refers to any device that converts electrical energy to mechanical energy using a solenoid. The device creates a magnetic field from electric current and uses the magnetic field to create linear motion. Common applications of solenoids are to power a switch, like the starter in an automobile, or a valve, such as in a sprinkler system.

Armature

An armature assembly for a solenoid valve allows for a valve member to be retained in the closed position through a biasing force being applied therein. A moveably supported armature bolt is movable between a first position and a second position. A valve member is coupled to the armature bolt and is configured to close with the armature bolt at the second position. An armature body is coupled to the armature bolt. A resilient member adapted to hold the armature bolt at the second position so as to retain the valve member in the closed position.

Diaphragm

The purpose of a diaphragm in a diaphragm type solenoid valve is to control the air within a certain space. These control valves can also be either open or closed, depending on the movement of the magnetic core.

Main Body

1.Different body material can be used in different working environment.
2.Different Connection Type can be used in different place, suitable for different installation way.
