CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve
video
CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: CA50T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 165000 pieces per month
Contact Now
Detailed Product Description
Port Size: 2'' Coil Voltage: 24VDC, 220VAC
Working Pressure Range: 0.3 To 0.8MPa Threaded Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T
Dresser Nut Pulse Jet Valve: CA25DD, RCA25DD, CA45DD Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM
Flanged Pulse Jet Valve: CAC25FS, CAC45FS Remote Pilot Pulse Jet Valve: RCA25DD, RCA20T, RCA45T, RCA50T, RCA62T
Application: Cartridge Filters, Envelope Filters, Ceramic Filters, Sintered Metal Fiber Filters
High Light:

CA50T Pulse Jet Valve

,

2'' Inch Pulse Jet Valve

,

Goyen Type CA50T

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve



This is CA50T Goyen Type Pulse Jet Valve; Reference No: CA50T000, CA50T001, CA50T010, CA50T000-300, CA50T000-305, CA50T000-331, CA50T001-300, CA50T001-305, CA50T001-331, CA50T010-300, CA50T010-305. 2'' inlet and outlet threaded port size; NBR diaphragm; 24V DC, 220V AC (50/60Hz) voltages for you to choose; other voltages can be customized.



Pulse Jet Valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.



Technical data of Right Angle Pulse Jet Valves:

Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Nonimal size
φ15
φ20
φ25
φ35
φ45
φ50
φ62
φ76
Port Size
G1/2''
G3/4''
G1''
G1 1/4''
G1 1/2''
G2''
G2 1/2''
G3''
Working pressure
0.3 to 0.8MPa
Temp. range
-5℃ to 55℃
Relative humidity
≤85%
Working
medium
Compressed clean air
Voltage
24VDC, 220VAC



Dimension of CA50T Goyen Type Pulse Jet Valve:

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 0



Video of CA50T Goyen Type Pulse Jet Valve:



Detail images of Goyen Type Pulse Jet Valves:

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 1



More Goyen Type Pulse Valve For You to Choose:


CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 2CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 3CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 4CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 5

       Threaded Type                   Immersion Type                Dresser Nut Type             Flanged Type

CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 6CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 7CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 8CA50T001-300 CA50T001-305 CA50T020-300 2'' Inch Pulse Jet Valve 9

          RCA Series                          Solenoid Coil                Armature Assembly            Pulse Controller



Installation:
1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank.
2. Ensure tank and pipes are free from dirt, rust or other particulate.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself.
5. Make electrical connections to solenoid or connect RCA pilot port to pilot valve (RCA valves only).
6. Apply moderate pressure to system and check for installation leaks.
7. Fully pressurise system.
8. Test fire and listen for proper actuation and crisp pulse noise.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
