CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve
video
CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: CA35T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 165000 pieces per month
Contact Now
Detailed Product Description
Port Size: 1 1/2'' Coil Voltage: 24VDC, 220VAC
Working Pressure Range: 0.3 To 0.8MPa Threaded Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T
Dresser Nut Pulse Jet Valve: CA25DD, RCA25DD, CA45DD Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM
Flanged Pulse Jet Valve: CAC25FS, CAC45FS Remote Pilot Pulse Jet Valve: RCA25DD, RCA20T, RCA45T, RCA50T, RCA62T
Application: Cartridge Filters, Envelope Filters, Ceramic Filters, Sintered Metal Fiber Filters
High Light:

CA35T Pulse Jet Valve

,

1.5'' Pulse Jet Valve

,

Goyen Type CA35T

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve



Brando has developed pulse valve and pulse jet valve for reverse pulse jet bag filters, offering precisely engineered valve of market need. Pulse Valve has just one moving part , the Spare diaphragm . The unique springless construction provides fast opening and closing of the valve. The high speed operation besides saving of compressed air,helps to provide shock air wave for dislodging of dust from filter bags. High flow,long life and fast diaphragm action produce reliable and economical operation.



Technical data of Right Angle Pulse Jet Valves:

Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Nonimal size
φ15
φ20
φ25
φ35
φ45
φ50
φ62
φ76
Port Size
G1/2''
G3/4''
G1''
G1 1/4''
G1 1/2''
G2''
G2 1/2''
G3''
Working pressure
0.3 to 0.8MPa
Temp. range
-5℃ to 55℃
Relative humidity
≤85%
Working
medium
Compressed clean air
Voltage
24VDC, 220VAC



Dimension of CA35T Goyen Type Pulse Jet Valve:

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 0



Video of CA35T Goyen Type Pulse Jet Valve:



Detail images of Goyen Type Pulse Jet Valves:

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 1



More Goyen Type Pulse Valve For You to Choose:


CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 2CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 3CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 4CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 5

       Threaded Type                   Immersion Type                Dresser Nut Type             Flanged Type

CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 6CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 7CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 8CA35T010-300 CA35T010-305 1.5'' CA35T Dust Collector Pulse Jet Valve 9

          RCA Series                          Solenoid Coil                Armature Assembly            Pulse Controller



Installation:
1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank.
2. Ensure tank and pipes are free from dirt, rust or other particulate.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself.
5. Make electrical connections to solenoid or connect RCA pilot port to pilot valve (RCA valves only).
6. Apply moderate pressure to system and check for installation leaks.
7. Fully pressurise system.
8. Test fire and listen for proper actuation and crisp pulse noise.
