K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit

K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit

  • K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit
  • K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit
K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: G102
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 4-8 day Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Size: 4'' Air Hole: With
Spring: With Packaging: Individual Sealed
Diaphragm Material: Nitrile/Buna Suitable Valve Number: CA89MM
Diaphragm Outer Distance: 200mm Center Distance: 184.5mm
Seat OD: 116.5mm
High Light:

K10200 Diaphragm Repair Kit

,

4'' Diaphragm Repair Kit

,

Goyen 4'' K10200

K10200 CA102MM RCA102MM Pulse Jet Valve 4'' Diaphragm Repair Kit



Pulse valve diaphragm commonly used material is rubber. The rubber diaphragm is mainly used in valves, regulating valves, automatic mechanical follow-up devices, switches and counters of flow rate, pressure, differential, liquid level, constant temperature and volume thermal compensation, etc. Its advantages are high reliability, good complexity, long working life and low cost. Uniform elastic construction can be used in all kinds of rubber. The rubber diaphragm has a long service life and can perform the operation synchronously with other control components to ensure the pulse compressed air injection. Even in extremely harsh working conditions, it can guarantee its normal work and long service life.


The operating temperature and pressure range of the diaphragm itself depends on the rubber, fabric and structure. The diaphragm can work at -50~100 ° c and 0.4~ 0.8mpa. Fluoro rubber and silicone rubber diaphragm can work at -80~232 ℃. Chlorol rubber diaphragm can work under pressure of 0.4~ 0.8mpa, with good air tightness and aging resistance.



Goyen Type Diaphragm Repair Kit:





Deference number:

Material Repair kit Fitted Valve Model Port Size
Buna/Nylon K2000(M1204B) CA20, RCA20, RCAC20 3/4''
K2003(M1174B)
K2016
K2034
Buna/Buna K2002(M764)
FKM K2007(M2080B)
K2004(1328B)
K2017
K2033
Buna/Nylon K2501(M1183B) CA25, RCA25, RCAC25 1''
K2529
K2549
K2531
K2545
K2546
Buna/Buna K2502(M736)
FKM K2503(M1887)
K2530
K2532
K2551
Buna/Nylon K2500(M1183)
CA32, RCA32, CA35, RCA35,
CA40, RCA40, CA45, RCA45
1-1/2''
K3500(M1581)
K4000(M1182)
K4502(M2162)
Buna/Buna K3502(M1591)
K4504(M2187)
FKM K2503(M1887)
K4004(M1761)
K4007(M1156)
K4503(M2163)

Buna/Nylon

Buna/Buna

K5004(M1638A) CA50, RCA50, CA62, RCA62 2'' , 2-1/2''
K5005(M1639A)
FKM K5000(M1157A)
K5002(M1528A)

Buna/Nylon

Buna/Buna

K7600 CA76, RCA76 3''
K7604
K7610
FKM K7602
Buna/Nylon K10200 CA102, RCA102 4''
Buna/Buna K10203
FKM K10201

Buna/Nylon

Buna/Buna

K8000 CA8, RCA8 8''
FKM


Dimension Diagram:

4'' Goyen Type Dust Collector Valve K10201 K10200 K10203 Diaphragm Repair Kit dimension



Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
*No leakage
*No Lubrication
* No Breakaway Force
* No Friction
* Functionality Over Wide Pressure Ranges
* High Strength
* Low Cost
* Simple Design
* Versatility
5. EPDM, FKM all available.
