K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm

K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm

  • K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm
  • K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm
K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: G76
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 4-8 day Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Size: 3'' Air Hole: With
Spring: With Packaging: Individual Sealed
Diaphragm Material: Nitrile/Buna Suitable Valve Number: CA76T, RCA76T, CA76MM, RCA76MM
Diaphragm Outer Distance: 200mm Center Distance: 184.5mm
Seat OD: 103mm
High Light:

K7610 Low Pressure Diaphragm

,

3'' Low Pressure Diaphragm

,

Goyen 3'' K7610

K7610 CA76/RCA76 MM T Series 3'' Inch 1 Bleed Hole Low Pressure Diaphragm



The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

The design with integral compression fittings will facilitate installation because there is no need for threaded piping.

The design with integral compression fittings will facilitate installation because there is no need for threaded piping.The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions.Integral pilot operated valves satisfy all relevant EC directives..The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust collector service applications



Goyen Type Diaphragm Repair Kit:





Deference number:

Material Repair kit Fitted Valve Model Port Size
Buna/Nylon K2000(M1204B) CA20, RCA20, RCAC20 3/4''
K2003(M1174B)
K2016
K2034
Buna/Buna K2002(M764)
FKM K2007(M2080B)
K2004(1328B)
K2017
K2033
Buna/Nylon K2501(M1183B) CA25, RCA25, RCAC25 1''
K2529
K2549
K2531
K2545
K2546
Buna/Buna K2502(M736)
FKM K2503(M1887)
K2530
K2532
K2551
Buna/Nylon K2500(M1183)
CA32, RCA32, CA35, RCA35,
CA40, RCA40, CA45, RCA45
1-1/2''
K3500(M1581)
K4000(M1182)
K4502(M2162)
Buna/Buna K3502(M1591)
K4504(M2187)
FKM K2503(M1887)
K4004(M1761)
K4007(M1156)
K4503(M2163)

Buna/Nylon

Buna/Buna

K5004(M1638A) CA50, RCA50, CA62, RCA62 2'' , 2-1/2''
K5005(M1639A)
FKM K5000(M1157A)
K5002(M1528A)

Buna/Nylon

Buna/Buna

K7600 CA76, RCA76 3''
K7604
K7610
FKM K7602
Buna/Nylon K10200 CA102, RCA102 4''
Buna/Buna K10203
FKM K10201

Buna/Nylon

Buna/Buna

K8000 CA8, RCA8 8''
FKM


Dimension Diagram:

3'' Goyen Type Pulse Valve K7600 K7604 K7610 K7602 Diaphragm Repair Kit dimension



Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
*No leakage
*No Lubrication
* No Breakaway Force
* No Friction
* Functionality Over Wide Pressure Ranges
* High Strength
* Low Cost
* Simple Design
* Versatility
5. EPDM, FKM all available.



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
