| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | BADV02 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Name: | COMBO Electronic Drain Valve | Valve Type: | 2/2 Way, Direct Acting |
|---|---|---|---|
| Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' NPT | Orifice Size: | 4.5mm |
| Valve Body Material: | Brass | Seal Material: | FKM |
| Power Connection: | DIN 43650A | Medium Temperature Range: | 34 - 131 °F |
| Applicable Industries: | Air Compressor | Strainer: | With |
| High Light: | COMBO Auto Drain Valve,Timed Auto Drain Valve,Jorc Type Combo |
||
COMBO Mesh Strainer Timed Air Compressor Auto Drain Valve
A timer drain discharges condensate from compressed air systems. The timer can be adjusted to discharge the condensate according to the specific needs of the compressed air system. The Brando range of timer drains is diverse and offers you drain solutions for pressures ranging from 0 to 7250 PSI. Multiple voltage options and valve material options are available.
The COMBO timer controlled condensate drain combines an adjustable electronic timer controlled drain, a ball valve and a mesh strainer into one compact easy to install package. The COMBO saves installation time and protects against large particles found in condensate, thanks to the integrated ball valve and strainer. The unit can be shut off from the compressed air system, enabling easy and safe work to be carried out.
The OPTIMUM is easy to install, simple to adjust . It includes a test switch, LED on/off indication and a serviceable valve. Most importantly, the large 4.5 mm orifice means it is perfect for difficult applications with high condensate flow rates and solid particulate contaminants.
Technical Data:
DIMENSION:
Dimension of OPTIMUM Type BADV01 Water Drain Valve:
Dimension of COMBO Type BADV02 Water Drain Valve:
More Details About Auto Drain Valve:
|
|
|
|
BAPC213037016 Solenoid Armture |
0200 Solenoid Coil | STRAINERS |
Feature:
Integrated mesh strainer, offering valve and orifice protection from larger particles found in condensate.
Integrated shut off valve, offering easy shut off of the valve for routine maintenance.
Dual inlet (1/2" and 1/4"), offering you installation flexibility.
A model is suitable for all applications, easy installation, fully automatic and maintenance free.
Interval time and discharge time is adjustable and have a test button.
Pressure 16 Bar, various pressure and port can be choose.
Full stain steel valve, anti-explosion valve can be choose.
CE Certificate, level of protection is IP65, insulation grade is H.
Accurate setting of drainage interval
Accurate setting of single drainage time
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
