Name: 4V410-15 1/2'' Inch Single Solenoid 5/2 Way Pilot Pneumatic Valve
Brand: Brando
SKU: 4V410-15
Rating: 4.6 (199 reviews)

Home Products Pneumatic Solenoid Valve

4V410-15 1/2'' Inch Single Solenoid 5/2 Way Pilot Pneumatic Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V410-15

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=Exhaust=1/2''	Valve Type:	Single Solenoid 5 Port 2 Position
Voltage:	220VAC 110VAC 24VDC 12VDC	Connector:	Terminal & Grommet
Working Pressure:	0.15 To 0.8MPa(21-114psi)	Temperature:	-20 To +70℃
Max. Frequency:	5 Cycle/sec	Body Material:	Aluminum Alloy
Fluid:	Air (to Be Filtered By 40 μm Filter Element)	Application:	Automation
High Light:	4V410-15 Pneumatic Valve , Pilot Pneumatic Valve , AirTAC Type 4V410-15

4V410-15 1/2'' Inch Single Solenoid 5/2 Way Pilot Pneumatic Valve

Pneumatic valve can also be called gas solenoid valve, solenoid valve or only air valve. Pneumatic solenoid valves are widely used in many different industries and applications can include compressed aerodynamic tools such as jackhammers and nail guns, vacuum cleaners, ventilation systems, laser printers and medical and dental pneumatic equipment.

Many industries rely on proportional solenoid valves to accurately regulate the flow of fluids, gases, and air in and out of components for a variety of applications. These valves may be made of plastic or metal (e.g. stainless steel). Pneumatic air valves facilitate multi-line valves because air can be easily compressed and directed to different outlets, while solenoid guides allow applications such as space heating to be easily automated, activated or remotely triggered.

5/2 Way Single Coil Pneumatic Solenoid Valve:4V110-06, 4V110-08, 4V210-06, 4V210-08, 4V310-08, 4V310-10, 4V410-15

5/2 Way Double Coil Pneumatic Solenoid Valve:4V120-06, 4V120-08, 4V220-06, 4V220-08, 4V320-08, 4V320-10, 4V420-15

5/3 Way Double Coil Pneumatic Solenoid Valve:4V130C-06, 4V130C-08, 4V230C-06, 4V230C-08, 4V330C-08, 4V330C-10, 4V430C-15

Technical Data:

Model	4v410-15	4V420-15	4V430C-15	4V430E-15	4V430P-15
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/2''
Orifice Size	50.00 mm² (Cv=2.79)		30.00 mm² (Cv=1.68)
Valve Type	5 port 2 position		5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof	1.5MPa (215psi)
Temperature ℃	-20 to 70
Material of Body	Aluminum alloy
Max. frequency	3cycle/sec

Dimension Diagram:

4V410-15 1/2'' Inch Single Solenoid 5/2 Way Pilot Pneumatic Valve 0

4V410(Grommet)

4V410-15 1/2'' Inch Single Solenoid 5/2 Way Pilot Pneumatic Valve 1

4V410(Terminal)

Brando is a Pneumatic Solenoid Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).

Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4V220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10.

2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15.

3. 3/2 Way Pneumatic Solenoid Valve: 3V110-06, 3V120-06, 3V210-06, 3V220-06, 3V210-08, 3V220-08, 3V310-08, 3V320-08, 3V310-10, 3V320-10, 3V410-15, 3V420-15.

4. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08.

Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
