Name: 1-1/2'' Inch DB114/C VNP VEM Series Pulse Jet Valve Diaphragm Set
Brand: Brando
SKU: DB114/C
Rating: 4.8 (166 reviews)

Home Products Diaphragm Repair Kit

1-1/2'' Inch DB114/C VNP VEM Series Pulse Jet Valve Diaphragm Set

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	DB114/C

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Plastic Bags, Cartons, Pallet
Delivery Time:	4-7 Days
Payment Terms:	L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	DB114/C Diaphragm Repair Kit	Suitable Valves:	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714
Diaphragm Material:	NBR (Nitrile)	Mounting Hole Size:	φ8mm
Diaphragm Outer Diameter:	φ116mm	Hole Center Distance:	φ119.5mm
Bleed Hole:	1	Spring:	2
Number Of Diaphragms:	2	Packaging:	Individual Plastic Bag Sealed
High Light:	1-1/2'' Inch Diaphragm Set , DB114/C Diaphragm Set , Mecair DB114/C

1-1/2'' Inch DB114/C VNP VEM Series Pulse Jet Valve Diaphragm Set

Pulse solenoid valve, also known as diaphragm valve, is the pulse bag filter dust cleaning and spraying system of compressed air "switch ", by pulse jet blowing control instrument output signal control, the filter bag row by row (chamber) to blow clean dust, so that the resistance of the dust collector to maintain in the set range, in order to ensure the dust collector processing capacity and dust efficiency.

In corrosive or explosive environment, corrosion resistance should be selected in priority according to safety requirements. The highest and lowest temperature of the environment should be selected within the permitted range.Often is vibration in environment, such as turbulence and occasions should choose special varieties, such as Marine electromagnetic valve. Voltage specifications with priority AC220V. As far as possible DC24V, high relative humidity in the environment and water drench, etc, should choose waterproof solenoid valve. Should choose rated current according to the power capacity and power consumption. Must pay attention to communication when starting the VA value is higher, the insufficient capacity should be preferred to choose indirect type solenoid valve.

Brando manufactures and exports wide range of replacement diaphragm repair kits for Mecair pulse valves. These are made of NBR The ordering code is DB16, DB18, DB112, DB114, DB116, DB120. The following is DB114/C diaphragm kit for Mecair 1.5'' pulse valve. And the quality of the diaphragm kits mean so much to the pulse valve service life and working steadily. Pls call or email us for availability, delivery times and for our competitive prices.

DB114/C suitable valves:

- VNP/VEP/VEM 214

- VNP/VEP/VEM 314

- VNP/VEP/VEM 414

- VNP/VEP/VEM 514

- VNP/VEP/VEM 614

- VNP/VEP/VEM 714

YouTube video of DB114/C Diaphragm Repair Kit For 1 1/2'' Mecair Pulse Valve:

Main dimension of NBR Diaphragm For VEM214 VNP214 VEM314 VNP314:

1-1/2'' Inch DB114/C VNP VEM Series Pulse Jet Valve Diaphragm Set 0

Details display of Repair Kit For Mecair VEM414 VNP414 Diaphragm Valve:

1-1/2'' Inch DB114/C VNP VEM Series Pulse Jet Valve Diaphragm Set 1

Available Models of Diaphragm Repair Kits For Mecair VNP/VEM Pulse Valves:

Ordering code	Fitted valve code	Valve port size	Material
DB16	VNP206, VEM206, VNP306, VEM306	3/4''	Nitrile/Buna
DB18	VNP208, VEM208, VNP308, VEM308, VNP408, VEM408, VNP608, VEM608, VNP708, VEM708	1''	Nitrile/Buna
DB112	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412	1-1/2''	Nitrile/Buna
DB114	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714	1-1/2''	Nitrile/Buna
DB116	VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716	2''	Nitrile/Buna
DB120	VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720	2-1/2''	Nitrile/Buna
Diaphragm kits typically contain the replacement diaphragm(s) as well as the spring(s). The most popular kits are shown above. If you don't see the kit you need, pls don't hesitate to contact us.
