| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE |
| Model Number: | BC-ZC-08A |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Inner Box,Carton,Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | T/T, Western Union, L/C, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Pulse Controller | Output Voltage: | 24VDC, 110VAC, 220VAC |
|---|---|---|---|
| Input Voltage: | 220VAC | Pulse Durtion: | 0.03 To 0.2 Seconds |
| Pulse Frequency: | 1 To 64 Seconds | Max Output Lines NO.: | 64 Channel |
| High Light: | Bag Filter Sequential Timer,Pulse Valve Sequential Controller,Sequential Timer Board |
||
8 Line Bag Filter Pulse Jet Valve Sequential Timer Controller
In nearly all industrial dust collectors there's a filter on top of them which works like the vacuum cleaner filter, the dust firstly goes in that part, then with the help of a pneumatic actuator, the filter gets punched with compressed air, then the dust particles will fall inside the main collector, which is like storage system of your vacuum cleaner. The Jet Pulse Controller is in charge of controlling those pneumatic actuators.
1. Pulse Width: Controller outputs an electrical signal duration.
2. Pulse Interval: Controller output time interval between the two signals.
3. Pulse Cycle: The time it takes for the control device to output an electrical signal to complete the required cycle.
Technical Data of Pulse Jet Valve Controller:
Product video of 8 Lines Pulse Controller:
Details Images of Pulse Jet Valve Controller:
All products for dust collector system:
| SBFEC Type Pulse Jet Valve | Goyen Type Pulse Jet Valve | ASCO Type Pulse Jet Valve | Turbo Type Pulse Jet Valve |
|
|
|
|
| Solenoid Valve Coil | Solenoid Valve Armature Assembly | Diaphragm Repair Kit | Pulse Controller |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
