The AB510 pneumatic solenoid coil is designed for use with the CKD series of normally closed solenoid valves. The system is designed for water, air, and gas. The working conditions are stable and thermoplastic. Other specific voltages and powers can be customized to your requirements. All solenoids in the system have stable power and good insulation to withstand harsh environments. This AB510 CKD Type solenoid valve coil is constructed of hollow core and black color with DIN connector. A solenoid valve coil is used to convert electrical energy into linear motion, an essential part for opening and closing solenoid valve.

AC Laminated Solenoid

The AC laminated Solenoid consist of a metal core and a coil of wire. The core is constructed with a laminated metal in order to reduce the stray current, this helps in improving the performance of the solenoid.

An AC solenoid has a special advantage because it can deliver a large amount of force in the first stroke. This is because they have an inrush current (An instantaneous high input current drawn by a power supply or electrical equipment when turn-on). They are capable of using more strokes than a DC laminated solenoid.

They are available in different configurations and ranges and they produce a clean buzzing sound when they are in operation.

An AC Laminated solenoid can be used in a variety of equipments that require immediate action, such as medical equipments, locks, vehicles, industrial equipments, printers, and in some of the household Appliances.

DC C-Frame Solenoid

The C frame refers to the design of the solenoid. The DC C-Frame solenoid has only a frame in the shape of the letter C which is covered around the coil.

The DC C-Frame solenoid is used in multiple day to day applications because of it more controlled stroke operation. Although it is said to be DC configuration but they can also be used in equipments designed for AC power.

Technical data of DIN43650A AB510 CKD Type Solenoid Valve Coil:

Main dimension of AB510 CKD Type Solenoid Coil For AB/AP Series Solenoid Valve:

Details display of AB510 CKD Type Electric Magnetic Coil φ16mm x 46mm x 40mm:

Production display of DC24V 220VAC AB510 CKD Type Electromagnetic Coil:

Other AB series (AB310, AB410) solenoid valve coils for your reference:

More display of AB510 CKD Type Solenoid Valve Coil in below Youtube Video:

Correctly repair the solenoid coil to reduce the occurrence of faults:

Any use of the product will cause certain faults, which is of course no exception for electromagnetic coils. The use of electromagnetic coils will bring great convenience to people, but if there is a fault, it will have a very bad impact on people, and people who pay attention to the maintenance of electromagnetic coils should pay attention.

1. It is necessary to test the voltage of the electromagnetic coil. When the attracting coil of the AC contactor has a voltage of 90% of the rated voltage of the electromagnetic coil, such an electromagnetic coil can work normally without worrying too much.

2. When using the electromagnetic coil, it is necessary to check whether there is overheating. If it is overheated, it will appear aging or discoloration. If this happens and it may be due to short circuit noise, it needs to be replaced at this time. To prevent accidents.

3. For the lead wire and the wiper wire of the electromagnetic coil, it is also necessary to check whether there is open welding or disconnection. If there is an abnormality, it must be repaired in time.

It is very important to correct the electromagnetic coil, which can reduce the occurrence of faults and avoid injury.

The relationship between the solenoid valve coil and the core:

The solenoid valve coil and the solenoid valve core are the most important components of the device, and their functions are different. The interaction between the two is the solenoid valve working and running. When the solenoid valve energizes the coil, the core will move quickly to change the direction of flow of the medium.

The energization and de-energization of the solenoid valve coil causes the valve to perform a switching operation. The core is the control switch of the valve to make the two work together. Once one of the two problems occurs, the entire device will not work. In general, the problem is that there is a problem with the solenoid valve coil. People can choose different ways to make changes according to different problems, but for the coil problem, people can directly change the coil to make the device work better.

The structure of the solenoid valve is relatively simple, and the working pressure difference is relatively small. Due to the speed of the switch, the solenoid coil may be subjected to a voltage surge, which may cause damage to the coil.
