Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50

Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50

  • Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50
Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: CXSWM, CXSWL
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Cylinder Type: Dual Rod Cylinder Bore Size (mm): 6, 10, 16, 20, 25, 32
Standard Stroke (mm): 10, 20, 30, 40, 50, 75, 100, 125, 150, 175, 200 Max Operating Pressure: 0.7 Mpa
Cushion: Rubber Bumper On Both Ends Port Size: M5x0.8, 1/8''
Bearing Type: Slide Bearing, Ball Bushing Bearing Piston Speed: 50 To 500mm/s
Highlight:

Double Rod Pneumatic Cylinders

,

Guide Rod Pneumatic Cylinders

,

SMC CXSWM10-50

Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50



Product Features of CXSW Series Pneumatic Cylinder:

1. The bore size of CXSW series dual rod cylinder is from 6 to 32mm;
2. The max. allowed load is 2~3 times larger than the CXS series;
3. Double piston rods, twice the thrust, high non-rotating accuracy, and high resistance to lateral load;
4. This cylinder is with magnet type.



The SMC Type CXSW Series Pneumatic Cylinder is a dual piston, double rod actuator with a non-rotating accuracy of ± 0.1°. The CXSWL high precision ball bushing bearing type allows for smooth operation that ensures stable travel resistance. The CXSWM slide bearing type provides lateral stability protecting it from side load impacts.



Specifications of CXSW Series Pneumatic Cylinder:

Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 0



Stroke of CXSW Series Pneumatic Cylinder:

Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 1


Ordering Code of CXSW Series Pneumatic Cylinder:
Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 2



Theoretical Output of CXSW Series Pneumatic Cylinder:

Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 3



Brando Supply Pneumatic Air Cylinders:



Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 4 Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 5 Double Guide Rod Pneumatic Air Cylinders SMC Type CXSWM10-50 6



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
