SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL

SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL

  • SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL
SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: CXSWM, CXSWL
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Cylinder Type: Dual Rod Cylinder Bore Size (mm): 6, 10, 16, 20, 25, 32
Standard Stroke (mm): 10, 20, 30, 40, 50, 75, 100, 125, 150, 175, 200 Max Operating Pressure: 0.7 Mpa
Cushion: Rubber Bumper On Both Ends Port Size: M5x0.8, 1/8''
Bearing Type: Slide Bearing, Ball Bushing Bearing Piston Speed: 50 To 500mm/s
High Light:

SMC CXSW Cylinder

,

SMC CXSWM Cylinder

,

SMC CXSWL Cylinder

SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL



SMC Type CXSW Series Pneumatic Cylinder is a dual piston double rod cylinder with non-rotating accuracy ± 0.1°. The CXSWL high precision ball bushing type allows for smooth operation that ensures stable travel resistance. The CXSWM slide bearing type provides lateral stability protecting it from side load impacts. Series CXSW is available in six bore sizes (6mm, 10mm, 15mm, 20mm, 25mm, 32mm) and stroke lengths up to 200mm. This series is very compact and has a very accurate non-rotating specification. It is suited for accurate pick-and-place applications or light duty material handling. The CXSW can be used with either reed or solid state switches.



Specifications of CXSW Series Pneumatic Cylinder:

SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 0



Stroke of CXSW Series Pneumatic Cylinder:

SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 1


Ordering Code of CXSW Series Pneumatic Cylinder:
SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 2



Theoretical Output of CXSW Series Pneumatic Cylinder:

SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 3



Brando Supply Pneumatic Air Cylinders:



Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 4 SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 5 SMC Type CXSW Series Dual Rod Pneumatic Air Cylinders CXSWM CXSWL 6
