| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | CDU |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Bore Size (mm): | 6, 10, 16, 20, 25, 32 | Standard Stroke (mm): | 5, 10, 15, 20, 25, 30, 40, 50 |
|---|---|---|---|
| Acting Type: | Double Acting | End Of Piston Rod: | Male Thread |
| Piston Speed: | 50 To 7500mm/s | Max Operating Pressure: | 0.7 Mpa |
| Cushion: | Rubber Bumper | Port Thread: | M5x0.8 |
| Highlight: | SMC Free Mount Cylinder,Air Cylinder SMC,SMC CDU20-20D |
||
Double Acting Single Rod Free Mount Air Cylinder SMC Type CDU20-20D
The series C(D)U single rod, double acting free mount cylinder saves space and allows direct and precise mounting. It is available in 6mm to 32mm bore sizes with stroke lengths up to 50mm. Options include auto-switch capabilities, free mount choices, recessed switch mounting grooves and rubber bumpers standard.
1. Bore sizes from 6mm to 32mm available
3. Stroke lengths up to 50mm
2. Any surfaces can be used for mounting
4. Space saving
5. Auto switch capable
Specifications of C(D)U Series Pneumatic Cylinder:
Stroke of C(D)U Series Pneumatic Cylinder:
Ordering Code of C(D)U Series Pneumatic Cylinder:
Theoretical Output of C(D)U Series Pneumatic Cylinder:
Brando Supply Pneumatic Air Cylinders:
