Name: Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting
Brand: BRANDO
SKU: ADVU
Rating: 4.5 (106 reviews)

Home Products Pneumatic Air Cylinders

Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	ADVU

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-7 work days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Series:	Compact Cylinder	Bore Size (mm):	12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm):	5, 10, 15, 20, 25, 30, 40, 50, 60, 80	Acting Type:	Double Acting
End Of Piston Rod:	Female Thread, Male Thread	Thread Sizes:	M3, M4, M5, M6, M8, M10, M12, M16, M10x1.25, M12x1.25, M16x1.5, M20x1.5, M27x2
Operating Medium:	Compressed Air
High Light:	Pneumatic Cylinder Double Acting , Festo Compact Cylinder ADVU , Festo ADVU-16-20-P-A

Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting

BRANDO offers a wide range of compact pneumatic cylinders. Our compact pneumatic cylinders are available in a wide selection of sizes, strokes and diameters, for unrivalled reliability and performance.

Compact pneumatics from BRANDO are commonly used in applications where space is limited. A compact pneumatic cylinder operates on the same principle as a pneumatic actuator, except that the small size allows the compact variants to be installed in just one third of the space required by ISO/VDMA standard cylinders.

BRANDO manufactures a wide range of compact actuators, including aluminium cylinders, compact air cylinders and ISO compact pneumatic rams. Their range of pneumatic cylinders are suitable for various different industries and applications, depending on the material composition.

Technical Data of ADVU Series Compact Pneumatic Cylinder:

Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting 0

Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting 1

Stroke of ADVU Series Compact Pneumatic Cylinder:

Bore (mm)		Standard Stroke (mm)	Max. Std Stroke (mm)
ADVU	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400
ADVULQ	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400

Ordering Code of ADVU Series Compact Pneumatic Cylinder:

Festo Type ADVU-16-20-P-A Compact Pneumatic Cylinder Double Acting 2

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder	Festo Type Pneumatic Cylinder	SMC Type Pneumatic Cylinder
