Festo Type ADVU-32-25-P-A Compact Air Cylinder Double Action

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	ADVU

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-7 work days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Series:	Compact Cylinder	Bore Size (mm):	12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm):	5, 10, 15, 20, 25, 30, 40, 50, 60, 80	Acting Type:	Double Acting
End Of Piston Rod:	Female Thread, Male Thread	Thread Sizes:	M3, M4, M5, M6, M8, M10, M12, M16, M10x1.25, M12x1.25, M16x1.5, M20x1.5, M27x2
Operating Medium:	Compressed Air
High Light:	Compact Air Cylinder , Air Cylinder Double Action , Festo ADVU-32-25-P-A

Festo Type ADVU-32-25-P-A Compact Air Cylinder Double Action

Today, compact pneumatic cylinders are the primary mechanism for linear actuation when space is limited. Frequently referenced as short-stroke cylinders, these devices are available with bore sizes ranging from 0.5 to 4 inches and standard strokes ranging from 0.0625 to 4 inches.

Compact air cylinders have a piston rod configuration (as opposed to rodless cylinders). Piston rod cylinders function in two ways: double-acting and single-acting.

Technical Data of ADVU Series Compact Pneumatic Cylinder:

Festo Type ADVU-32-25-P-A Compact Air Cylinder Double Action 0

Festo Type ADVU-32-25-P-A Compact Air Cylinder Double Action 1

Stroke of ADVU Series Compact Pneumatic Cylinder:

Bore (mm)		Standard Stroke (mm)	Max. Std Stroke (mm)
ADVU	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400
ADVULQ	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400

Ordering Code of ADVU Series Compact Pneumatic Cylinder:

Festo Type ADVU-32-25-P-A Compact Air Cylinder Double Action 2
