| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | ADVU |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Series: | Compact Cylinder | Bore Size (mm): | 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 |
|---|---|---|---|
| Standard Stroke (mm): | 5, 10, 15, 20, 25, 30, 40, 50, 60, 80 | Acting Type: | Double Acting |
| End Of Piston Rod: | Female Thread, Male Thread | Thread Sizes: | M3, M4, M5, M6, M8, M10, M12, M16, M10x1.25, M12x1.25, M16x1.5, M20x1.5, M27x2 |
| Operating Medium: | Compressed Air | ||
| High Light: | Compact Air Cylinders,Compact Pneumatic Cylinders,Festo ADVU |
||
Festo Type ADVU Series Compact Pneumatic Air Cylinders
Compact air cylinder, ADVU, AEVU:
1. Single-acting or double-acting cylinder with a wide range of mounting options.
2. 50% less installation space than comparable ISO cylinders to ISO 15552
3. Wide range of variants for customized applications
4. Piston rod with internal or external thread
5. Magnetic piston for position sensing
Technical Data of ADVU Series Compact Pneumatic Cylinder:
Stroke of ADVU Series Compact Pneumatic Cylinder:
| Bore (mm) | Standard Stroke (mm) | Max. Std Stroke (mm) | |
| ADVU | 12 | 5 10 15 20 25 30 40 | 1 ~ 200 |
| 16 | 1 ~ 200 | ||
| 20 | 5 10 15 20 25 30 40 50 | 1 ~ 200 | |
| 25 | 1 ~ 200 | ||
| 32 | 5 10 15 20 25 30 40 50 60 80 | 1 ~ 300 | |
| 40 | 1 ~ 300 | ||
| 50 | 10 15 20 25 30 40 50 60 80 | 1 ~ 300 | |
| 63 | 1 ~ 300 | ||
| 80 | 10 15 20 25 30 40 50 60 80 | 1 ~ 400 | |
| 100 | 1 ~ 400 | ||
| 125 | 1 ~ 400 | ||
| ADVULQ | 12 | 5 10 15 20 25 30 40 | 1 ~ 200 |
| 16 | 1 ~ 200 | ||
| 20 | 5 10 15 20 25 30 40 50 | 1 ~ 200 | |
| 25 | 1 ~ 200 | ||
| 32 | 5 10 15 20 25 30 40 50 60 80 | 1 ~ 300 | |
| 40 | 1 ~ 300 | ||
| 50 | 10 15 20 25 30 40 50 60 80 | 1 ~ 300 | |
| 63 | 1 ~ 300 | ||
| 80 | 10 15 20 25 30 40 50 60 80 | 1 ~ 400 | |
| 100 | 1 ~ 400 | ||
| 125 | 1 ~ 400 | ||
Ordering Code of ADVU Series Compact Pneumatic Cylinder:
