Name: Festo Type DSNU-10-40-PPV-A Pneumatic Air Cylinder Aluminum Round Body
Brand: BRANDO
SKU: DSNU
Rating: 5 (166 reviews)

Home Products Pneumatic Air Cylinders

Festo Type DSNU-10-40-PPV-A Pneumatic Air Cylinder Aluminum Round Body

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	DSNU

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-7 work days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Series:	Piston Rod Cylinder	Bore Size (mm):	8, 10, 12, 16, 20, 25, 32, 40, 50, 63
Standard Stroke (mm):	10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500	Mode Of Operation:	Double Acting
Operating Pressure Range:	0.1 To 1.0 MPa	Conforms To Standard:	ISO 6432
Highlight:	Pneumatic Round Body Cylinder , Festo Pneumatic Cylinder DSNU , Air Pneumatic Cylinders

Festo Type DSNU-10-40-PPV-A Pneumatic Air Cylinder Aluminum Round Body

Pneumatic cylinders are commonly referred to as an Air cylinder, they provide motion and force to industrial and automation applications. Our range of Pneumatic cylinders create linear motion using a collection of pistons.

In contrast to a standard Single-acting Pneumatic cylinder, a Double-acting Pneumatic cylinder uses the output force in both forward and backward motion. This is done through the use of both the air exhaust and air pressure valves, these valves use compressed air to push the piston road in both directions.

Specifications of DSNU Series Pneumatic Cylinder:

Bore Size (mm)

Acting Type

DSNU

Double Acting

ESNU

Single Acting

Port Size

G1/8''

G1/4''

G3/8''

Piston Rod thread

M10x1.25

M12x1.25

M16x1.25

Cushioning Type

Adjustable Cushion

Cushioning Length (PPV)

12mm

15mm

17mm

14mm

18mm

20mm

21mm

Fluid

Air (to be filtered by 40μm filter element)

Operating Pressure Range

0.1 to 1.0 MPa

Temprature (℃)

-20 to +70

Stroke of DSNU Series Pneumatic Cylinder:

Bore Size (mm)		Standard Stroke (mm)	Max. Std Stroke	Stroke Tolerance
Double Acting	8	10, 25, 40, 50, 80, 100	100	+1
	10	10, 25, 40, 50, 80, 100	100	+1
	12	10, 25, 40, 50, 80, 100, 125, 150, 160, 200	200	+1.5
Double Acting, Adjustable Cushion	16	10, 25, 40, 50, 80, 100, 125, 150, 160, 200	200	+1.5
	20	10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300	300	+1.5
	25	10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500	500	+2
	32		500	+2
	40		500	+2
	50		500	+2
	63		500	+2
Single Acting	8	10, 15, 20, 25, 30, 40, 50	50	+1
	10		50	+1
	12		50	+1
	16	10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100	100	+1
	20	10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150	150	+1
	25		150	+1
	32		150	+1
	40		150	+1
	50		150	+1
	63		150	+1

Ordering Code of DSNU Series Pneumatic Cylinder:

Festo Type DSNU-10-40-PPV-A Pneumatic Air Cylinder Aluminum Round Body 0

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
