Place of Origin: | Ningbo, China |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | DSNU |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner Box, Carton, Pallet |
Delivery Time: | 4-7 work days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 100000 pcs per month |
Product Series: | Piston Rod Cylinder | Bore Size (mm): | 8, 10, 12, 16, 20, 25, 32, 40, 50, 63 |
---|---|---|---|
Standard Stroke (mm): | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500 | Mode Of Operation: | Double Acting |
Operating Pressure Range: | 0.1 To 1.0 MPa | Conforms To Standard: | ISO 6432 |
Highlight: | Round Body Air Cylinder,ISO 6432 Pneumatic Cylinder,Festo DSNU-25-25-PPV-A |
Festo Type DSNU-25-50-PPV-A Round Body Air Cylinder Pneumatic ISO 6432
All air cylinders fall into one of two categories: single acting or double acting.
Single acting cylinders can power movement in one direction by allowing compressed air to enter and move the piston through a single inlet. After the air has moved through, a spring pushes the piston back into place. Single cylinders use about half the amount of compressed air that double acting cylinders use.
Double acting cylinders have two outlets on either side of the piston that allow compressed air in and out to push the piston back and forth. Like single acting cylinders, double acting cylinder airflow is controlled by valves, or air lines.
Specifications of DSNU Series Pneumatic Cylinder:
Bore Size (mm) | 8 | 10 | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | ||
Acting Type | DSNU | Double Acting | ||||||||||
ESNU | Single Acting | |||||||||||
Port Size | M5 | G1/8'' | G1/4'' | G3/8'' | ||||||||
Piston Rod thread | M4 | M6 | M8 | M10x1.25 | M12x1.25 | M16x1.25 | ||||||
Cushioning Type | - | Adjustable Cushion | ||||||||||
Cushioning Length (PPV) | - | 12mm | 15mm | 17mm | 14mm | 18mm | 20mm | 21mm | ||||
Fluid | Air (to be filtered by 40μm filter element) | |||||||||||
Operating Pressure Range | 0.1 to 1.0 MPa | |||||||||||
Temprature (℃) | -20 to +70 |
Stroke of DSNU Series Pneumatic Cylinder:
Bore Size (mm) | Standard Stroke (mm) | Max. Std Stroke | Stroke Tolerance | |
Double Acting | 8 |
10, 25, 40, 50, 80, 100 |
100 | +1 |
10 |
10, 25, 40, 50, 80, 100 |
100 | +1 | |
12 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200 |
200 | +1.5 | |
Double Acting, Adjustable Cushion |
16 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200 |
200 | +1.5 |
20 | 10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300 | 300 | +1.5 | |
25 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500 |
500 | +2 | |
32 | 500 | +2 | ||
40 | 500 | +2 | ||
50 | 500 | +2 | ||
63 | 500 | +2 | ||
Single Acting | 8 | 10, 15, 20, 25, 30, 40, 50 | 50 | +1 |
10 | 50 | +1 | ||
12 | 50 | +1 | ||
16 | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100 | 100 | +1 | |
20 | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150 | 150 | +1 | |
25 | 150 | +1 | ||
32 | 150 | +1 | ||
40 | 150 | +1 | ||
50 | 150 | +1 | ||
63 | 150 | +1 |
Ordering Code of DSNU Series Pneumatic Cylinder:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon Bao
Tel: 86-13454729544
Fax: 86-574-83879820
