| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | DSNU |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Series: | Piston Rod Cylinder | Bore Size (mm): | 8, 10, 12, 16, 20, 25, 32, 40, 50, 63 |
|---|---|---|---|
| Standard Stroke (mm): | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500 | Mode Of Operation: | Double Acting |
| Operating Pressure Range: | 0.1 To 1.0 MPa | Conforms To Standard: | ISO 6432 |
| Highlight: | Festo Pneumatic Cylinder,Festo DSNU-25-50-PPV-A,Double-Acting Cylinder |
||
Festo Type DSNU-25-50-PPV-A Pneumatic Cylinder Double-Acting ISO 6432
Pneumatic cylinders or actuators give direct movement and apply power on hardware for different mechanical procedures. They push, pull, pivot and clip. They move and position items or machine parts. Pneumatic cylinders are basic, practical, simple to-introduce gadgets. They can create high power and a surfeit of speeds. Their movement can be slowed down without causing internal damage.
Pneumatic cylinders are the most befitting answer to your prayers regarding force and motion needs in OEM applications. The explanations behind this is they are basic in design strength, easy to establish, affordable in cost, and solid in execution. Pneumatic cylinders are structured in an assortment of sizes, styles, and designs. OEMs need to pick the pneumatic cylinder cautiously, with the goal that it will buck up the application well.
Specifications of DSNU Series Pneumatic Cylinder:
| Bore Size (mm) | 8 | 10 | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | ||
| Acting Type | DSNU | Double Acting | ||||||||||
| ESNU | Single Acting | |||||||||||
| Port Size | M5 | G1/8'' | G1/4'' | G3/8'' | ||||||||
| Piston Rod thread | M4 | M6 | M8 | M10x1.25 | M12x1.25 | M16x1.25 | ||||||
| Cushioning Type | - | Adjustable Cushion | ||||||||||
| Cushioning Length (PPV) | - | 12mm | 15mm | 17mm | 14mm | 18mm | 20mm | 21mm | ||||
| Fluid | Air (to be filtered by 40μm filter element) | |||||||||||
| Operating Pressure Range | 0.1 to 1.0 MPa | |||||||||||
| Temprature (℃) | -20 to +70 | |||||||||||
Stroke of DSNU Series Pneumatic Cylinder:
| Bore Size (mm) | Standard Stroke (mm) | Max. Std Stroke | Stroke Tolerance | |
| Double Acting | 8 |
10, 25, 40, 50, 80, 100 |
100 | +1 |
| 10 |
10, 25, 40, 50, 80, 100 |
100 | +1 | |
| 12 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200 |
200 | +1.5 | |
|
Double Acting, Adjustable Cushion |
16 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200 |
200 | +1.5 |
| 20 | 10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300 | 300 | +1.5 | |
| 25 |
10, 25, 40, 50, 80, 100, 125, 150, 160, 200, 250, 300, 350, 400, 450, 500 |
500 | +2 | |
| 32 | 500 | +2 | ||
| 40 | 500 | +2 | ||
| 50 | 500 | +2 | ||
| 63 | 500 | +2 | ||
| Single Acting | 8 | 10, 15, 20, 25, 30, 40, 50 | 50 | +1 |
| 10 | 50 | +1 | ||
| 12 | 50 | +1 | ||
| 16 | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100 | 100 | +1 | |
| 20 | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150 | 150 | +1 | |
| 25 | 150 | +1 | ||
| 32 | 150 | +1 | ||
| 40 | 150 | +1 | ||
| 50 | 150 | +1 | ||
| 63 | 150 | +1 | ||
Ordering Code of DSNU Series Pneumatic Cylinder:
