| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA45FS |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Flange Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1.5'';1-1/2''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 1 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| High Light: | CA45FS Diaphragm Pulse Valve,Flange Diaphragm Pulse Valve,Goyen Type CA45FS |
||
CA45FS 1-1/2'' 1.5'' Inch Flange Integral Pilot Diaphragm Pulse Valve
Maintenance of dust collector:
1. The wind-locking device of the dust collector must ensure that the lock air is effective and the material is smoothly discharged. If the lock air is invalid, the negative pressure will be seriously lost in the return ash port, resulting in poor dust collection effect. Material, when the dust is severe, it will be filled with the inside of the dust collector, causing the dust to fail.
2. The pulse valve inspection of the dust collector ensures flexible and effective action. If there is air leakage, the diaphragm and internal corresponding parts (such as: valve core, spring, orifice) should be replaced. If the pulse valve fails, the blowing effect will be poor. The surface area of the filter bag cannot be removed to reduce the dust collection capacity.
3. Check the lifting cylinder of the dust collector to ensure that the lifting cylinder moves smoothly and ensure that the cylinder gland is tightened and not loose. Otherwise, the gland pressure will not be tight and can not be lifted; if the pressure is not tight, it will cause the cleaning to be cleaned. If it cannot be lifted, the corresponding air chamber cannot be collected.
4. The electromagnetic two-way five-way reversing valve inspection, to ensure smooth operation, no air leakage, no dust inside, otherwise it will cause the failure of the lifting cylinder.
Technical Data of Goyen Pulse Jet Valve:
|
Model
|
CAC25FS
|
CAC45FS
|
|
Working Pressure
|
0.3~0.8Mpa
|
|
|
Working Temperature
|
-5~+55℃
|
|
|
Voltage
|
AC24V, AC110V, AC220V, DC24V
|
|
|
Inlet and Out Pipe Size
|
1 1/2'' IN, 1'' OUT
|
2'' IN, 1 1/2'' OUT
|
|
Remote or Integral
|
Integral Pilot
|
|
|
Connection Type
|
Weldless Flange
|
|
|
Body Material
|
Aluminium ADC12
|
|
|
Diaphragm Material
|
NBR(Common), Viton(Available)
|
|
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Five tips for extending the life of Goyen type FS series flange connection pulse jet valve for dust collector bag filter:
1. First ensure that the voltage of the dust collector pulse jet valve is stable when in use.
2. The air supply pressure of the dust collector must be too low or the dust source is unstable. Before use, it is necessary to check the wiring line of the dust removal trouble regularly.
3. Replace the defective dust collector pulse jet valve parts in time. In the environment with temperature difference, the dust collector pulse jet valve should be used with the oil water separator.
4. The newly installed dust collector first cleans the solder joint impurities in the air bag.
5. Ensure that the clean air temperature of the valve body entering the dust collector pulse jet valve is not lower than -5 °C.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Mia
Tel: +8613454729544
