Place of Origin: | Ningbo, China |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | DNC |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner Box, Carton, Pallet |
Delivery Time: | 4-7 work days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 100000 pcs per month |
Product Series: | Piston Rod Cylinder | Bore Size (mm): | 32, 40, 50, 63, 80, 100, 125 |
---|---|---|---|
Standard Stroke (mm): | 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 | Acting Type: | Double Acting |
Operating Pressure Range: | 0.15 To 1.0 MPa | Proof Pressure: | 1.5 MPa |
Highlight: | Adjustable Cushioned Air Cylinder,Festo Air Cylinder DNC,Festo DNC-80-250-PPV-A |
Adjustable Cushioned Pneumatic Air Cylinder Festo Type DNC-80-250-PPV-A
Air cylinders are pneumatic linear actuators driven by pressure differential in the cylinder chambers. Compressed gas (typically air) acts as the power to impart a force and cause actuation. The compressed gas is allowed to expand due to the pressure gradient, and forces a piston to move in the desired direction. One side of a piston flange can be pressurized to provide force and motion with a spring (providing return force after pressure is released), or both sides can be alternately pressurized for bi-directional powered motion.
Air cylinders are used in applications which push, pull, and lift objects, close doors, or hold, remove, and position parts. They are commonly used in materials handling and processing. Air cylinders are also important in fail safe systems.
Specifications of DNC Series Pneumatic Cylinder:
Bore Size (mm) | 32 | 40 | 50 | 63 | 80 | 100 | 125 | ||
Acting Type | Double Acting | ||||||||
Fluid | Air (to be filtered by 40μm filter element) | ||||||||
Operating Pressure Range | 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi) | ||||||||
Proof Pressure | 1.5 MPa (15 bar) (215 psi) | ||||||||
Temprature (℃) | -20 to +80 | ||||||||
Speed Range (mm/s) | 30 to 800 | ||||||||
Cushion Type | Variable cushion | ||||||||
Port Size | 1/8'' | 1/4'' | 3/8'' | 1/2'' |
Stroke of DNC Series Pneumatic Cylinder:
Bore Size (mm) | Standard Stroke (mm) | Max. Std Stroke | Max. Stroke |
32 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500 |
1000 | 1800 |
40 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800 |
1200 | 1800 |
50 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 |
1200 | 1800 |
63 | 1500 | 1800 | |
80 | 1500 | 1800 | |
100 | 1500 | 1800 | |
125 | 1500 | 1800 |
Ordering Code of DNC Series Pneumatic Cylinder:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
