Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting

Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting

  • Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting
Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: DNC
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Series: Piston Rod Cylinder Bore Size (mm): 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm): 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 Acting Type: Double Acting
Operating Pressure Range: 0.15 To 1.0 MPa Proof Pressure: 1.5 MPa
High Light:

Tie Rod Pneumatic Cylinder

,

Pneumatic Cylinder Double Acting

,

Festo DNC-80-50-PPV-A

Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting



A pneumatic cylinder is also called pneumatic actuators is a device that is used in industrial automation applications to provide motion and force. A pneumatic cylinder uses compressed air to create force. This device is widely used in automated systems, machines, and processes. Movement of the products is done directly or indirectly by the pneumatic cylinder and the load will be moved by pushing, pulling, etc. These devices are not costly and can be installed easily. This device can create a huge amount of force over a board range of velocities without overheating or internal damage.


Specifications of DNC Series Pneumatic Cylinder:

Bore Size (mm) 32 40 50 63 80 100 125
Acting Type Double Acting
Fluid Air (to be filtered by 40μm filter element)
Operating  Pressure Range 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi)
Proof Pressure 1.5 MPa (15 bar) (215 psi)
Temprature (℃) -20 to +80
Speed Range (mm/s) 30 to 800
Cushion Type Variable cushion
Port Size 1/8'' 1/4'' 3/8'' 1/2''


Stroke of DNC Series Pneumatic Cylinder:

Bore Size (mm) Standard Stroke (mm) Max. Std Stroke Max. Stroke
32

25, 50, 75, 80, 100, 125, 150, 160, 175,

200, 250, 300, 350, 400, 450, 500

1000 1800
40

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250,

300, 350, 400, 450, 500, 600, 700, 800

1200 1800
50

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300,

350, 400, 450, 500, 600, 700, 800, 900, 1000

1200 1800
63 1500 1800
80 1500 1800
100 1500 1800
125 1500 1800


Ordering Code of DNC Series Pneumatic Cylinder:


Festo Type DNC-80-50-PPV-A Tie Rod Pneumatic Cylinder Double Acting 0



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
