| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | DTA-ZT-25 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Straight Through Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 1 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| High Light: | 1'' Inch Dust Collector Valve,Straight Through Dust Collector Valve,Through Type remote Pilot |
||
DTA-ZT-25 1'' Inch Straight Through Electric Dust Collector Valve
Pulse Valve Internal Structure and Main Parts:
| Part Name | Material |
| Solenoid coil | high quanlity enamelled wire |
| Armature assembly | SS304, 430FR |
| Small common cap | ADC aluminum |
| Diaphragm | NBR (nitrile, buna-n) |
| Top end cap | ADC aluminum |
| Big spring | SS304 |
| Screws | SS302 |
| Seal | NBR, Viton, all can be customized |
| Main body | ADC aluminum |
How to choose
1. AC220V and DC24V are preferred as far as possible for voltage specifications.
2, in the environment with high relative humidity and rain drops and other occasions, should choose waterproof solenoid valve.
3. The rated current and consumed power shall be selected according to the power supply capacity. It shall be noted that the VA value is higher during ac starting, and indirect guided solenoid valve shall be preferred when the capacity is insufficient.
Main Dimension:
353 Series Pulse Jet Valve For Dust Collector System:
CA/RCA Series Pulse Jet Valve:
DMF Series Pulse Jet Valve:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
