Airtac Type SDA63X50 Compact Cylinder Pneumatic 63mm Bore 50mm Stroke

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	SDA

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-7 work days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Series:	SDA Compact Cylinder	Bore Size (mm):	12, 16, 20, 25, 32, 40, 50, 63, 80, 100
Standard Stroke (mm):	5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 75, 80, 90, 100, 110, 120, 130	Acting Type:	Double Acting, Single Acting_ Push Type, Single Acting_Pull Type
Operating Pressure Range:	Double Acting: 0.15 To 1.0 MPa, Single Acting: 0.2 To 1.0 MPa	Proof Pressure:	1.5 MPa
High Light:	Compact Cylinder Pneumatic , Airtac Compact Cylinder , Airtac SDA63X50

Airtac Type SDA63X50 Compact Cylinder Pneumatic 63mm Bore 50mm Stroke

Compact pneumatic cylinders use compressed air to produce force in a linear motion and provide a quieter operation than electric motors and hydraulics. Our durable and compant cylinders are offered with or without a magnet to meet your requirements and have an operating temperature range of -4°F to 176°F. Available in bore sizes from 1/8'' to 4'' and 12mm to 100mm and strokes from 5mm to 150mm.

Specifications of SDA Series Pneumatic Cylinder:

Bore Size (mm)

100

Acting Type

Double Acting

Single Acting_ Push Type, Single Acting_Pull Type

Fluid

Air (to be filtered by 40μm filter element)

Operating Pressure Range

Double Acting

0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi)

Single Acting

0.2 to 1.0 MPa (2.0 to 10.0 bar) (28 to 145 psi)

Proof Pressure

1.5 MPa (15 bar) (215 psi)

Temprature (℃)

-20 to +70

Speed Range (mm/s)

Double Acting: 30 to 500, Single Acting: 50 to 500

Cushion Type

Bumper

Port Size

M5 x 0.8

1/8''

1/4''

3/8''

Stroke of SDA Series Pneumatic Cylinder:

Airtac Type SDA63X50 Compact Cylinder Pneumatic 63mm Bore 50mm Stroke 0

Symbol of SDA Series Pneumatic Cylinder:

Ordering Code of SDA Series Pneumatic Cylinder:
Airtac Type SDA63X50 Compact Cylinder Pneumatic 63mm Bore 50mm Stroke 2

Criteria for selection: Cylinder thrust:

Installation & Usage:

1. When load changes in the wonk, the cylinder wih abundant output capacity shall be ed.

2. Relative cylinder wth high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion.

3. Necessasy protection measure shall be taken in the evironment with higher humidity. much dust or water drops, oil dust and welding dregs.

4. Dirty substances in the pipe must be eliminated before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.

5. The medium used by cyinder shall be fitered to 40μm or below.

6. As both of the front cover and piston of the cylinder are short. typically too large stroke can not be ed.

7. Anti-freezing measure shall be adopted under low temperature environment prevent moisture freezing.

8. The cylinder shall avoid the inluence of side load in operation to maintain the normal work of cylinder and extend the service life.

9. If the cylinder is dismantled and stored for a long time, please conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports. The front and back cover can not be dismantled, which shall be especially noticed.
