COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve

COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve

  • COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve
  • COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve
COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: COMBO
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Name: COMBO Electronic Drain Valve Valve Type: 2/2 Way, Direct Acting
Port Size: 1/8'', 1/4'', 3/8'', 1/2'' NPT Orifice Size: 4.5mm
Valve Body Material: Brass Seal Material: FKM
Power Connection: DIN 43650A Medium Temperature Range: 34 - 131 °F
Applicable Industries: Air Compressor Strainer: With
High Light:

COMBO Auto Drain Valve

,

Timer Auto Drain Valve

,

Jorc Type COMBO

COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve



Brando is a Air Compressor Auto Drain Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The air compressor Auto Drain Valve is suitable for a wide range of compressed air applications including compressors, receivers, filters and refrigerated air dryers.

The COMBO auto drain valve combines an adjustable electronic timer controlled drain, a ball valve and a mesh strainer into one compact easy to install package.

The OPTIMUM auto drain valve with an easily adjustable electronic timer, a Direct Acting Solenoid Valve, a large orifice and options for a brass or stainless steel body, this drain provides reliable compact condensate removal.



Technical Data:



Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 FormA
Voltages
24V DC, 110V AC, 220V AC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
NEMA4(IP65)
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131.F



DIMENSION:



Dimension of OPTIMUM Type BADV01 Water Drain Valve:

Dimension of OPTIMUM Type BADV01 Water Drain Valve:



Dimension of COMBO Type BADV02 Water Drain Valve:

Dimension of COMBO Type BADV02 Water Drain Valve:

More Details About Auto Drain Valve:

COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve 2 COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve 3 COMBO Air Compressor Electronic Timer Condensate Auto Drain Valve 4

BAPC213037016

Solenoid Armture

0200 Solenoid Coil STRAINERS



Feature:



Integrated mesh strainer, offering valve and orifice protection from larger particles found in condensate.
Integrated shut off valve, offering easy shut off of the valve for routine maintenance.
Dual inlet (1/2" and 1/4"), offering you installation flexibility.

A model is suitable for all applications, easy installation, fully automatic and maintenance free.
Interval time and discharge time is adjustable and have a test button.
Pressure 16 Bar, various pressure and port can be choose.
Full stain steel valve, anti-explosion valve can be choose.
CE Certificate, level of protection is IP65, insulation grade is H.
Accurate setting of drainage interval
Accurate setting of single drainage time
