| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | MA |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Series: | MA Round Body Air Cylinder Stainless Steel | Bore Size (mm): | 16, 20, 25, 32, 40, 50, 63 |
|---|---|---|---|
| Standard Stroke (mm): | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500 | Acting Type: | Double Acting, Single Acting |
| Operating Pressure Range: | Double Acting: 0.15 To 1.0 MPa, Single Acting: 0.2 To 1.0 MPa | Proof Pressure: | 1.5 MPa |
| High Light: | Pneumatic Cylinder 25mm Bore 50mm Stroke,Mini Pneumatic Cylinder,Micro Air Cylinder |
||
25mm Bore 50mm Stroke Mini Pneumatic Cylinder Airtac Type MA25x50
A pneumatic cylinder is also called pneumatic actuators is a device that is used in industrial automation applications to provide motion and force. A pneumatic cylinder uses compressed air to create force. This device is widely used in automated systems, machines, and processes. Movement of the products is done directly or indirectly by the pneumatic cylinder and the load will be moved by pushing, pulling, etc. These devices are not costly and can be installed easily. This device can create a huge amount of force over a board range of velocities without overheating or internal damage.
Specifications of MA Series Pneumatic Cylinder:
| Bore Size (mm) | 16 | 20 | 25 | 32 | 40 | 50 | 63 | ||
| Acting Type | MSA / MTA | Single Acting | - | ||||||
| MA / MAD / MAJ | Double Acting | - | |||||||
| MAR | - | Double Acting | |||||||
| MAC / MACD / MACJ | Double Acting with cushion | ||||||||
| Fluid | Air (to be filtered by 40μm filter element) | ||||||||
| Operating Pressure Range | Double Acting | 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi) | |||||||
| Single Acting | 0.2 to 1.0 MPa (2.0 to 10.0 bar) (28 to 145 psi) | ||||||||
| Proof Pressure | 1.5 MPa (15 bar) (215 psi) | ||||||||
| Temprature (℃) | -20 to +70 | ||||||||
| Speed Range (mm/s) | Double Acting: 30 to 800, Single Acting: 50 to 800 | ||||||||
| Cushion Type |
MAC / MACD / MACJ Series: Variable cushion; Other Series: Bumper |
||||||||
| Port Size | M5x0.8 | 1/8'' | 1/4'' | ||||||
Stroke of MA Series Pneumatic Cylinder:
Symbol of MA Series Pneumatic Cylinder:
Ordering Code of MA Series Pneumatic Cylinder:
Criteria for selection: Cylinder thrust:
Installation & Usage:
1. When load changes in the work, the cylinder with abundant output capacity shall be ed.
2. Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion.
3. Necessary protection measure shall be taken in the environment with higher humidity, much dust or water drops, oil dust and welding dregs.
4. Dirty substances in the pipe must be eliminated before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.
5. The medium used by cylinder shall be filtered to 40μm or below.
6. Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.
7. The cylinder shall be carried out test run without load before application. Prior to run, buffer shall be turned to the minimum and gradually released to avoid the damage on cylinder caused by excessive impact.
8. The cylinder shall avoid the influence of side load in operation to maintain the normal work of cylinder and extend the service life.
9. If the cylinder is dismantled and stored for a long time, please conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports.
