Name: 24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil
Brand: Brando
SKU: BB14542505
Rating: 4.9 (166 reviews)

Home Products Solenoid Valve Coil

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	BB14542505

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	500000 set per month

Contact Now

Detailed Product Description

Type:	0545 110-030 NASS Type	Material:	Thermoset Resin, Copper
Product Name:	0545 110-030 NASS Type Solenoid Valve Coil System 13	Voltage:	AC220V AC110V/ DC12V DC24V (±10%)
Hole Size:	14.6 Mm	Ambient Temperature:	- 20 °C ~ + 50 °C
Application:	Water Solenoid Valve And Electronic Drain Valve	Insulation Class:	F, H
Connection Type:	DIN43650A	Degree Of Protection With Connector:	IP 65 (IP 67 On Request)
High Light:	113-030-0144 Solenoid Valve Coil , 113-030-0135 Solenoid Valve Coil , 113-030-0129 113-030-0127 Solenoid Bobine

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil 0

Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:

Code No	Voltages	Frequency(Hz)	Power (W)	Power (VA)
113-030-0123	24vDC		4,1
113-030-0144	24VAC	50		8,8
113-030-0144	24VAC	60		7,6
113-030-0128	220VAC	50		9,0
113-030-0128	240VAC	60		9,2
113-030-0142	230VAC	50		8,8
113-030-0142	230VAC	60		7,6
113-030-0121	220VAC	50		14,0
113-030-0124	24VDC	-	7,9
113-030-0135	24VAC	50		14,0
113-030-0135	24VAC	60		12,0
113-030-0279	110 VAC	50		13,9
113-030-0279	110VAC	60		12,2
113-030-0125	24VDC	-	11,9
113-030-0129	24VAC	50		21,0
113-030-0129	24VAC	60		18,0
113-030-0126	110VAC	50		21,5
113-030-0141	230 VAC	50		22,0
113-030-0141	230VAC	60		19,0
113-030-0120	12VDC	-	17,5
113-030-0127	24VAC	50		25,0
113-030-0132	24VDC	-	18,5
113-030-0120	36VAC	50		25,0
113-030-0137	110VAC	50		27,5
113-030-0140	110VAC	60		26,5
113-030-0137	120VAC	60		28,0
113-030-0133	220VAC	50		25,5
113-030-0122	220VAC	50		22,0
113-030-0138	230VAC	50		25,5
113-030-0133	240VAC	60		25,0
113-030-0138	240VAC	60		27,0

Phyical map of 113-030-0028 nass type electromagnetic coil:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil 1

Applicatoin of nass type 113-030-0035 electric magnetic coil:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil 2

More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:

Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
