1, Our coil is available in different sizes and with different electrical terminations, we have professional technicians to develop as your drawing or sample or your special demands.
2, We use heat resistant bobbin moulded with 30% glass filled thermoplastic polyester material
3, The enameled copper wire has features of class H 200℃ according to IEC 317-8
4, The yoke for leading magnetic field we chosen as low carbon iron
5, Encapsulation with high quality specially designed glass filled nylon
6, The use of other materials is possible upon special agreements. All coils are rated to class F and to IP65.
7, The coil is designed and constructed in accordance to EN 60204.1 and VDE 0580 and it is suitable for industrial ambient conditions.
8, For use in special ambients with high humidity, please do not hesitate to contact with us.
Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:
Code No
Voltages
Frequency(Hz)
Power (W)
Power (VA)
113-030-0123
24vDC
4,1
113-030-0144
24VAC
50
8,8
113-030-0144
24VAC
60
7,6
113-030-0128
220VAC
50
9,0
113-030-0128
240VAC
60
9,2
113-030-0142
230VAC
50
8,8
113-030-0142
230VAC
60
7,6
113-030-0121
220VAC
50
14,0
113-030-0124
24VDC
-
7,9
113-030-0135
24VAC
50
14,0
113-030-0135
24VAC
60
12,0
113-030-0279
110 VAC
50
13,9
113-030-0279
110VAC
60
12,2
113-030-0125
24VDC
-
11,9
113-030-0129
24VAC
50
21,0
113-030-0129
24VAC
60
18,0
113-030-0126
110VAC
50
21,5
113-030-0141
230 VAC
50
22,0
113-030-0141
230VAC
60
19,0
113-030-0120
12VDC
-
17,5
113-030-0127
24VAC
50
25,0
113-030-0132
24VDC
-
18,5
113-030-0120
36VAC
50
25,0
113-030-0137
110VAC
50
27,5
113-030-0140
110VAC
60
26,5
113-030-0137
120VAC
60
28,0
113-030-0133
220VAC
50
25,5
113-030-0122
220VAC
50
22,0
113-030-0138
230VAC
50
25,5
113-030-0133
240VAC
60
25,0
113-030-0138
240VAC
60
27,0
Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:
Phyical map of 113-030-0028 nass type electromagnetic coil:
Applicatoin of nass type 113-030-0035 electric magnetic coil:
More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:
Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
