Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | BB14542505 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | negotiation |
Packaging Details: | Inner Box, Carton, Pallet |
Delivery Time: | 4-8 days |
Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
Supply Ability: | 500000 set per month |
Type: | 0545 110-030 NASS Type | Material: | Thermoset Resin, Copper |
---|---|---|---|
Product Name: | 0545 110-030 NASS Type Solenoid Valve Coil System 13 | Voltage: | AC220V AC110V/ DC12V DC24V (±10%) |
Hole Size: | 14.6 Mm | Ambient Temperature: | - 20 °C ~ + 50 °C |
Application: | Water Solenoid Valve And Electronic Drain Valve | Insulation Class: | F, H |
Connection Type: | DIN43650A | Degree Of Protection With Connector: | IP 65 (IP 67 On Request) |
High Light: | 0545 Electrical Coil,113-030-0120 Electrical Coil,Nass Type Magnet 12V DC |
0545 12V DC 113-030-0120 Auto Drain Valve Replacement Electrical Coil
There are many factors that affect the magnetic force of solenoid valve coil, mainly the wire diameter of the coil and the magnetic conductivity area of the steel, that is, the magnetic flux. When the ac coil is pulled directly from the core, there is no need for a short circuit ring inside the core. If the ac current is abnormal, it will burn out the solenoid valve coil. Moreover, there is a short circuit ring inside the ac coil core, which can reduce vibration. Once the dc solenoid valve coil is removed from the core, the coil current will increase rapidly.
Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:
Code No | Voltages | Frequency(Hz) |
Power (W)
|
Power (VA) |
113-030-0123 | 24vDC | 4,1 | ||
113-030-0144 | 24VAC | 50 | 8,8 | |
113-030-0144 | 24VAC | 60 | 7,6 | |
113-030-0128 | 220VAC | 50 | 9,0 | |
113-030-0128 | 240VAC | 60 | 9,2 | |
113-030-0142 | 230VAC | 50 | 8,8 | |
113-030-0142 | 230VAC | 60 | 7,6 | |
113-030-0121 | 220VAC | 50 | 14,0 | |
113-030-0124 | 24VDC | - | 7,9 | |
113-030-0135 | 24VAC | 50 | 14,0 | |
113-030-0135 | 24VAC | 60 | 12,0 | |
113-030-0279 | 110 VAC | 50 | 13,9 | |
113-030-0279 | 110VAC | 60 | 12,2 | |
113-030-0125 | 24VDC | - | 11,9 | |
113-030-0129 | 24VAC | 50 | 21,0 | |
113-030-0129 | 24VAC | 60 | 18,0 | |
113-030-0126 | 110VAC | 50 | 21,5 | |
113-030-0141 | 230 VAC | 50 | 22,0 | |
113-030-0141 | 230VAC | 60 | 19,0 | |
113-030-0120 | 12VDC | - | 17,5 | |
113-030-0127 | 24VAC | 50 | 25,0 | |
113-030-0132 | 24VDC | - | 18,5 | |
113-030-0120 | 36VAC | 50 | 25,0 | |
113-030-0137 | 110VAC | 50 | 27,5 | |
113-030-0140 | 110VAC | 60 | 26,5 | |
113-030-0137 | 120VAC | 60 | 28,0 | |
113-030-0133 | 220VAC | 50 | 25,5 | |
113-030-0122 | 220VAC | 50 | 22,0 | |
113-030-0138 | 230VAC | 50 | 25,5 | |
113-030-0133 | 240VAC | 60 | 25,0 | |
113-030-0138 | 240VAC | 60 | 27,0 |
Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:
Phyical map of 113-030-0028 nass type electromagnetic coil:
Applicatoin of nass type 113-030-0035 electric magnetic coil:
More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:
Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
