Place of Origin: | Ningbo, China |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | MA |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner Box, Carton, Pallet |
Delivery Time: | 4-7 work days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 100000 pcs per month |
Product Series: | MA Round Body Air Cylinder Stainless Steel | Bore Size (mm): | 16, 20, 25, 32, 40, 50, 63 |
---|---|---|---|
Standard Stroke (mm): | 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500 | Acting Type: | Double Acting, Single Acting |
Operating Pressure Range: | Double Acting: 0.15 To 1.0 MPa, Single Acting: 0.2 To 1.0 MPa | Proof Pressure: | 1.5 MPa |
Highlight: | Mini Pneumatic Cylinders,Stainless Steel Pneumatic Cylinders,Airtac MA32X50 |
Airtac Type MA32X50 Mini Pneumatic Air Cylinders Stainless Steel
Pneumatic air cylinders are either single-acting (spring return or spring extent) or double-acting. Single-acting cylinders require compressed to either extend or return the piston and the spring force is in the opposite direction. In a double-acting cylinder, compressed air is used for both the extension and retraction of the rod depending on where the high pressure is.Double acting cylinders are most commonly used. With multiple different configurations of rod diameter, stroke length, force in/out, and pressure ranges there is a pneumatic cylinder for almost any application requiring linear motion. We also have options with a magnetic piston for position feedback capabilities as well as adjustable damping for added control of cushioning.
BRANDO’s wide range of pneumatic cylinders allow you to find a product to meet almost any application requirements and we ensure they are made from high quality material, tested, calibrated, and come to you at a competitive price.
Specifications of MA Series Pneumatic Cylinder:
Bore Size (mm) | 16 | 20 | 25 | 32 | 40 | 50 | 63 | ||
Acting Type | MSA / MTA | Single Acting | - | ||||||
MA / MAD / MAJ | Double Acting | - | |||||||
MAR | - | Double Acting | |||||||
MAC / MACD / MACJ | Double Acting with cushion | ||||||||
Fluid | Air (to be filtered by 40μm filter element) | ||||||||
Operating Pressure Range | Double Acting | 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi) | |||||||
Single Acting | 0.2 to 1.0 MPa (2.0 to 10.0 bar) (28 to 145 psi) | ||||||||
Proof Pressure | 1.5 MPa (15 bar) (215 psi) | ||||||||
Temprature (℃) | -20 to +70 | ||||||||
Speed Range (mm/s) | Double Acting: 30 to 800, Single Acting: 50 to 800 | ||||||||
Cushion Type |
MAC / MACD / MACJ Series: Variable cushion; Other Series: Bumper |
||||||||
Port Size | M5x0.8 | 1/8'' | 1/4'' |
Stroke of MA Series Pneumatic Cylinder:
Symbol of MA Series Pneumatic Cylinder:
Ordering Code of MA Series Pneumatic Cylinder:
Criteria for selection: Cylinder thrust:
Installation & Usage:
1. When load changes in the work, the cylinder with abundant output capacity shall be ed.
2. Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion.
3. Necessary protection measure shall be taken in the environment with higher humidity, much dust or water drops, oil dust and welding dregs.
4. Dirty substances in the pipe must be eliminated before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.
5. The medium used by cylinder shall be filtered to 40μm or below.
6. Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.
7. The cylinder shall be carried out test run without load before application. Prior to run, buffer shall be turned to the minimum and gradually released to avoid the damage on cylinder caused by excessive impact.
8. The cylinder shall avoid the influence of side load in operation to maintain the normal work of cylinder and extend the service life.
9. If the cylinder is dismantled and stored for a long time, please conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports.
