0545 36mm Width 113-030-0100 230V AC Thermoplast Solenoid Valve Coil

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	BB14542505

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	5-8 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Hole Size:	14.5mm	Height:	42.5mm
Width:	36.0mm	Voltage:	AC220V, AC110V, DC24V, DC12V
Power:	28VA, 20W, 14W	Connector:	DIN43650A
Insulation Class:	H	Enameled Wire Material:	Copper
Suitable Valve Series:	Air Compressor Auto Drain Valve
High Light:	113-030-0100 Solenoid Valve Coil , Thermoplast Solenoid Valve Coil , Nass Type Magnet 230V

0545 36mm Width 113-030-0100 230V AC Thermoplast Solenoid Valve Coil

The electronic drain valve is mainly composed of a solenoid valve with 0545/0543 solenoid coil, a timer and a junction box. The automatic drain valve is set for a period of time to perform a drain operation on a regular basis.

1. The hot, humid and moisture-laden compressed air from the air compressor is first pre-cooled by air to the air heat exchanger; then the pre-cooled air is passed through the refrigerant in the air-to-refrigerant heat exchanger. The circulation loop is further cooled to exchange heat with the cold air that has been cooled from the evaporator to the pressure dew point to further reduce the temperature of the compressed air.

2. After that, the compressed air enters the evaporator and exchanges heat with the refrigerant. The temperature of the compressed air drops to 0 ° C - 8 ° C. The moisture in the air is precipitated at this temperature, and the water condensed in the compressed air is passed through the condenser. The oil and impurities are separated and discharged through the automatic drainer.

3. The dry low-temperature air enters the air to exchange heat with the air exchanger, and the temperature rises and then outputs.

Dimension of BB14542505 Solenoid Valve Coil :

Technical Data:

Order Number	Voltage	Frequency	Power
Order Number	Voltage	Frequency	[W]	[VA]
113-030-0123	24V DC	-	4,1
113-030-0144	24V AC	50		8,8
113-030-0144	24V AC	60		7,6
113-030-0128	220V AC	50		9,0
113-030-0128	240V AC	60		9.2
113-030-0142	230V AC	50		8.8
113-030-0142	230V AC	60		7.6
113-030-0121	220V AC	50		14,0
113-030-0124	24V DC	-	7,9
113-030-0135	24V AC	50		14,0
113-030-0135	24V AC	60		12,0
113-030-0279	110V AC	50		13,9
113-030-0279	110V AC	60		12,2
113-030-0125	24V DC	-	11,9
113-030-0129	24V AC	50		21,0
113-030-0129	24V AC	60		18,0
113-030-0126	110V AC	50		21,5
113-030-0141	230V AC	50		22,0
113-030-0141	230V AC	60		19,0
113-030-0120	12V DC	-	17,5
113-030-0127	24V AC	50		25,0
113-030-0132	24V DC	-	18,5
113-030-0120	36V AC	50		25,0
113-030-0137	110V AC	50		27,5
113-030-0140	110V AC	60		26,5
113-030-0137	120V AC	60		28,0
113-030-0133	220V AC	50		25,5
113-030-0122	220V AC	50		22,0
113-030-0138	230V AC	50		25,5
113-030-0133	240V AC	60		25,0
113-030-0138	240V AC	60		27,0

Solenoid Coil Production Line:

0545 36mm Width 113-030-0100 230V AC Thermoplast Solenoid Valve Coil 1

Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
