110V AC 113-030-0036 113-030-0037 Nass Type Magnet Electrical Coil

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	BB14542004

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner boxes, carton, pallet
Delivery Time:	4-9 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	250000 sets per month

Contact Now

Detailed Product Description

Type:	Electronic Drain Valve Accessories	Material:	BMC, Brass
Product Name:	Solenoid Coils	Voltage:	DC12V/DC24V/AC110V/AC220V
Dimension(Hole X Width X Height):	14mm X 29mm X 42mm	Power:	Solenoid Control
Color:	Black (Other Color Can Be Customized)	Application:	TM30 Electronic Drain Valve Automatic Control
Insulation Class:	H	Connection Type:	DIN43650B
High Light:	113-030-0036 Electrical Coil , 113-030-0037 Electrical Coil , 113-030-0038 113-030-0049 Solenoid Coil

110V AC 113-030-0036 113-030-0037 Nass Type Magnet Electrical Coil

This 0543 solenoid coil is NASS type 110-030 system 13 solenoid coil, which is a thermosetting coil.
In daily life, need to pay attention to the solenoid valve coil maintenance and maintenance, the service period will be long. According to investigation, now many coil manufacturers of solenoid valve coil sealing waterproof use method is pouring asphalt and resin glue, is to say the coil pouring in the shell. This method can be waterproof, but once the coil is burned out, it is difficult to take it out, which may cause damage to the life of the coil shell.

Technical parameter of electronic drain valve solenoid coils:

Code No	Voltage	Frequency (Hz)	Power W/VA
113-030-0042	24VDC		2,0
113-030-0045	48VDC		2,1
113-030-0032	48VDC		1,6
113-030-0032	220VAC	50		6,4
113-030-0032	230VAC	50		6,6
113-030-0032	240VAC	50		5,7
113-030-0278	12VDC		6,0
113-030-0026	24VDC		6,1
113-030-0029	24VAC	50		10,8
113-030-0029	24VAC	60		9,6
113-030-0036	110VAC	50		11,1
113-030-0036	120VAC	60		11,7
113-030-0033	220VAC	50		10,8
113-030-0044	12VAC	50		19,3
113-030-0044	12VAC	50		17,1
113-030-0027	24VDC		11,0
113-030-0039	24VAC	50		17,9
113-030-0039	24VAC	60		15,6
113-030-0037	110VAC	50		17,6
113-030-0037	120VAC	50		18,3
113-030-0034	220VAC	50		18,1
113-030-0034	240VAC	60		18,9
113-030-0033	240VAC	50		11,4
113-030-0047	12VDC		15,0
113-030-0028	24VDC		15,0
113-030-0040	24VAC	50		21,8,
113-030-0040	24VAC	50		19.4
113-030-0043	48VAC	50		26,2
113-030-0043	48VAC	50		23,2
113-030-0052	48VAC	50		19,0
113-030-0052	48VAC	50		16,6
113-030-0038	110VAC	50		24,8
113-030-0049	110VAC	50		21,7
113-030-0049	110VAC	50		19,2
113-030-0038	120VAC	50		26,1
113-030-0041	195VDC		16,6
113-030-0035	220VAC	50		22,0
113-030-0050	230vAC	50		21,4
113-030-0050	230VAC	50		19,0
113-030-0031	240VAC	50		17,9
113-030-0035	240VAC	50		23,2

Main dimension of 5043/5045 solenoid coils for water electronic drain valve:

110V AC 113-030-0036 113-030-0037 Nass Type Magnet Electrical Coil 0

Detail enlargement of 14 mm Inside Hole 42 High electric solenoid coils:

110V AC 113-030-0036 113-030-0037 Nass Type Magnet Electrical Coil 1

Connection of AC220V/DC24V black electromagnetic coils in electronic drain valve:

110V AC 113-030-0036 113-030-0037 Nass Type Magnet Electrical Coil 2
