12V DC 113-030-0278 113-030-0047 System 13 30mm Width Nass Magnet Coil

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	BB14542004

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner boxes, carton, pallet
Delivery Time:	4-9 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	250000 sets per month

Contact Now

Detailed Product Description

Type:	Electronic Drain Valve Accessories	Material:	BMC, Brass
Product Name:	Solenoid Coils	Voltage:	DC12V/DC24V/AC110V/AC220V
Dimension(Hole X Width X Height):	14mm X 29mm X 42mm	Power:	Solenoid Control
Color:	Black (Other Color Can Be Customized)	Application:	TM30 Electronic Drain Valve Automatic Control
Insulation Class:	H	Connection Type:	DIN43650B
High Light:	113-030-0278 Nass Magnet Coil , 113-030-0047 Nass Magnet Coil , 12V DC Nass Magnet Coil

12V DC 113-030-0278 113-030-0047 System 13 30mm Width Nass Magnet Coil

Features:

1. Product Name: Nass Magnet Replacement Solenoid Coil
2. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC, 240VAC (50/60Hz)
3. Power: 22VA, 13W, 20W
4. Connector: DIN 43650 Form A Plug
5. Insulation Class: Class H, Class, F
6. Protection Class: IP65
7. Application Examples: Auto Drain Valve, Shako Solenoid Valve, such like PU220, PU225, SPU225, etc.

Technical parameter of electronic drain valve solenoid coils:

Code No	Voltage	Frequency (Hz)	Power W/VA
113-030-0042	24VDC		2,0
113-030-0045	48VDC		2,1
113-030-0032	48VDC		1,6
113-030-0032	220VAC	50		6,4
113-030-0032	230VAC	50		6,6
113-030-0032	240VAC	50		5,7
113-030-0278	12VDC		6,0
113-030-0026	24VDC		6,1
113-030-0029	24VAC	50		10,8
113-030-0029	24VAC	60		9,6
113-030-0036	110VAC	50		11,1
113-030-0036	120VAC	60		11,7
113-030-0033	220VAC	50		10,8
113-030-0044	12VAC	50		19,3
113-030-0044	12VAC	50		17,1
113-030-0027	24VDC		11,0
113-030-0039	24VAC	50		17,9
113-030-0039	24VAC	60		15,6
113-030-0037	110VAC	50		17,6
113-030-0037	120VAC	50		18,3
113-030-0034	220VAC	50		18,1
113-030-0034	240VAC	60		18,9
113-030-0033	240VAC	50		11,4
113-030-0047	12VDC		15,0
113-030-0028	24VDC		15,0
113-030-0040	24VAC	50		21,8,
113-030-0040	24VAC	50		19.4
113-030-0043	48VAC	50		26,2
113-030-0043	48VAC	50		23,2
113-030-0052	48VAC	50		19,0
113-030-0052	48VAC	50		16,6
113-030-0038	110VAC	50		24,8
113-030-0049	110VAC	50		21,7
113-030-0049	110VAC	50		19,2
113-030-0038	120VAC	50		26,1
113-030-0041	195VDC		16,6
113-030-0035	220VAC	50		22,0
113-030-0050	230vAC	50		21,4
113-030-0050	230VAC	50		19,0
113-030-0031	240VAC	50		17,9
113-030-0035	240VAC	50		23,2

Main dimension of 5043/5045 solenoid coils for water electronic drain valve:

12V DC 113-030-0278 113-030-0047 System 13 30mm Width Nass Magnet Coil 0

Detail enlargement of 14 mm Inside Hole 42 High electric solenoid coils:

12V DC 113-030-0278 113-030-0047 System 13 30mm Width Nass Magnet Coil 1

Connection of AC220V/DC24V black electromagnetic coils in electronic drain valve:

12V DC 113-030-0278 113-030-0047 System 13 30mm Width Nass Magnet Coil 2

The working principle of the automatic drain valve of the dryer:
The refrigerating dryer (hereinafter referred to as the dryer) is compressed by the air compressor, cooled by the rear cooler, separated by the gas-water separator, and the compressed air of the buffer tank is generally saturated, and its relative humidity is 100%. Moreover, it contains impurities such as oil and solid particles. This compressed air cannot be directly used and needs to be dried and purified. In order to discharge the condensate in the dryer in time and completely, the easiest way is to open a drain hole at the end of the evaporator to continuously discharge the condensed water generated in the machine. But its drawbacks are also obvious. Because the compressed air is also continuously discharged while draining, the compressed air pressure drops rapidly. This is not allowed for the gas source system. Manually draining the hand valve is feasible, but it requires a lot of manpower and a series of management troubles. With the automatic drainer, the water in the machine can be automatically eliminated at regular (quantitative).
