Name: 230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil
Brand: Brando
SKU: BB14542004
Rating: 4.7 (132 reviews)

Home Products Solenoid Valve Coil

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	BB14542004

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner boxes, carton, pallet
Delivery Time:	4-9 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	250000 sets per month

Contact Now

Detailed Product Description

Type:	Electronic Drain Valve Accessories	Material:	BMC, Brass
Product Name:	Solenoid Coils	Voltage:	DC12V/DC24V/AC110V/AC220V
Dimension(Hole X Width X Height):	14mm X 29mm X 42mm	Power:	Solenoid Control
Color:	Black (Other Color Can Be Customized)	Application:	TM30 Electronic Drain Valve Automatic Control
Insulation Class:	H	Connection Type:	DIN43650B
High Light:	113-030-0032 Magnetic Coil , 113-030-0050 Magnetic Coil , Nass Magnet 230V AC Coil

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Features:

1. Product Name: Nass Magnet Replacement Solenoid Coil
2. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC, 240VAC (50/60Hz)
3. Power: 22VA, 13W, 20W
4. Connector: DIN 43650 Form A Plug
5. Insulation Class: Class H, Class, F
6. Protection Class: IP65
7. Application Examples: Auto Drain Valve, Shako Solenoid Valve, such like PU220, PU225, SPU225, etc.

Technical parameter of electronic drain valve solenoid coils:

Code No	Voltage	Frequency (Hz)	Power W/VA
113-030-0042	24VDC		2,0
113-030-0045	48VDC		2,1
113-030-0032	48VDC		1,6
113-030-0032	220VAC	50		6,4
113-030-0032	230VAC	50		6,6
113-030-0032	240VAC	50		5,7
113-030-0278	12VDC		6,0
113-030-0026	24VDC		6,1
113-030-0029	24VAC	50		10,8
113-030-0029	24VAC	60		9,6
113-030-0036	110VAC	50		11,1
113-030-0036	120VAC	60		11,7
113-030-0033	220VAC	50		10,8
113-030-0044	12VAC	50		19,3
113-030-0044	12VAC	50		17,1
113-030-0027	24VDC		11,0
113-030-0039	24VAC	50		17,9
113-030-0039	24VAC	60		15,6
113-030-0037	110VAC	50		17,6
113-030-0037	120VAC	50		18,3
113-030-0034	220VAC	50		18,1
113-030-0034	240VAC	60		18,9
113-030-0033	240VAC	50		11,4
113-030-0047	12VDC		15,0
113-030-0028	24VDC		15,0
113-030-0040	24VAC	50		21,8,
113-030-0040	24VAC	50		19.4
113-030-0043	48VAC	50		26,2
113-030-0043	48VAC	50		23,2
113-030-0052	48VAC	50		19,0
113-030-0052	48VAC	50		16,6
113-030-0038	110VAC	50		24,8
113-030-0049	110VAC	50		21,7
113-030-0049	110VAC	50		19,2
113-030-0038	120VAC	50		26,1
113-030-0041	195VDC		16,6
113-030-0035	220VAC	50		22,0
113-030-0050	230vAC	50		21,4
113-030-0050	230VAC	50		19,0
113-030-0031	240VAC	50		17,9
113-030-0035	240VAC	50		23,2

Main dimension of 5043/5045 solenoid coils for water electronic drain valve:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil 0

Detail enlargement of 14 mm Inside Hole 42 High electric solenoid coils:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil 1

Connection of AC220V/DC24V black electromagnetic coils in electronic drain valve:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil 2
