| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V420-15 |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 to 14 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100000 pcs per month |
| Port Size: | In=Out=Exhaust=1/2'' | Valve Type: | Double Solenoid 5 Port 2 Position |
|---|---|---|---|
| Voltage: | 220VAC 110VAC 24VDC 12VDC | Connector: | Terminal & Grommet |
| Working Pressure: | 0.15 To 0.8MPa(21-114psi) | Temperature: | -20 To +70℃ |
| Max. Frequency: | 5 Cycle/sec | Body Material: | Aluminum Alloy |
| Fluid: | Air (to Be Filtered By 40 μm Filter Element) | Application: | Automation |
| High Light: | 4V420-15 Pneumatic Solenoid Valve,5/2 Way Pneumatic Solenoid Valve,AirTAC Type 4V420-15 |
||
4V420-15 1/2'' 5/2 Way Double Solenoid Pneumatic Solenoid Valve
Other industry terms for pneumatic solenoid valves are solenoid air valves, direct action solenoid valves, direct operation solenoid valves, direct air pilot solenoid valves, solenoid operation direction control valves, direction control solenoid valves, universal solenoid valves, two-way solenoid valves, three-way solenoid valves and four-way solenoid valves.
Pneumatic solenoid valves are used to direct or stop the flow of compressed air to the equipment. They can be used for example to drive cylinders, larger industrial valves or pneumatic tools. Directional control valves are usually classified by two numbers, the first number indicating the number of ports and the second number indicating the number of states. The most common types are 3/2, 5/2, and 5/3. Valves can be single-acting or double-acting (one or two solenoid valves). Different operating voltages can be obtained by replacing the electromagnetic coils. Several models are available for manifold installation, please note the platform dimensions when selecting valves and manifes. Optionally, the valve body has the Namur configuration to install the valve directly onto the actuator.
5/2 Way Single Coil Pneumatic Solenoid Valve:4V110-06, 4V110-08, 4V210-06, 4V210-08, 4V310-08, 4V310-10, 4V410-15
5/2 Way Double Coil Pneumatic Solenoid Valve:4V120-06, 4V120-08, 4V220-06, 4V220-08, 4V320-08, 4V320-10, 4V420-15
5/3 Way Double Coil Pneumatic Solenoid Valve:4V130C-06, 4V130C-08, 4V230C-06, 4V230C-08, 4V330C-08, 4V330C-10, 4V430C-15
Technical Data:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal pilot or external pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
|||
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
||||
|
Proof
|
1.5MPa (215psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum alloy
|
||||
|
Max. frequency
|
3cycle/sec
|
||||
Dimension Diagram:
4V420(Grommet)
4V420(Terminal)
Product Features:
1. Pilot-oriented mode: Internal pilot or external pilot.
2. Structure in sliding column mode: good tightness and sensitive reaction.
3. Three position solenoid valves have three kinds of central functionfor your choice.
4. Double control solenoid valves have memory function.
5. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life.
6. No need to add oil for lubrication.
7. It is available to form integrated valve group with the base to save installation space.
8. Affiliated manual devices are equipped to facilitate installation and debugging.
9. Several standard voltage grades are optional.
