Name: AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve
Brand: Brando
SKU: 4V320-08
Rating: 5 (113 reviews)

Home Products Pneumatic Solenoid Valve

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V320-08

Payment & Shipping Terms:

Minimum Order Quantity:	100 PCS
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=Exhaust=1/4''	Valve Type:	Double Solenoid 5 Port 2 Position
Voltage:	220VAC 110VAC 24VDC 12VDC	Connector:	Terminal & Grommet
Working Pressure:	0.15 To 0.8MPa(21-114psi)	Temperature:	-20 To +70℃
Max. Frequency:	5 Cycle/sec	Body Material:	Aluminum Alloy
Fluid:	Air (to Be Filtered By 40 μm Filter Element)	Application:	Automation
High Light:	AirTAC Type Pneumatic Air Valve , 4V320-08 Pneumatic Air Valve , 4V320-08 Air Control Valve

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve

Application Field & Working Principle of 4V series 5/2 Way Pneumatic Solenoid Valve:

5/2 or 5/3 way AirTAC type pneumatic solenoid valves are used to control the flow of the compressed air with 12V DC, 24V DC, 110V AC and 220V AC, and widely applied in the industrial fields like chemical, petroleum, pharmaceutical, automotive, light industry, food, mineral processing, electroplating, metallurgy, textiles etc.

The pilot-operated two-position four-way or five-way (4/2-way or 5/2-way) solenoid valve pushes the valve stem in the valve by the intake pressure from the pilot hole to realize the gas (liquid) reversing function. Pilot-operated 4/2-way or 5/2-way solenoid valves are general purpose for both air and liquid due to different structure and sealing form.

Technical Data:

Model	4V310-08 4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10 4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/4''		In=Out=3/8'' Exhaust=1/4''
Orifice Size	25.00 mm2 (Cv=1.40)	18.00 mm2 (Cv=1.00)	30.00 mm2 (Cv=1.68)	18.00 mm2 (Cv=1.00)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa(21~114psi)
Proof Pressure	1.5MPa(215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	4 cycle/sec	4 cycle/sec	4 cycle/sec	4 cycle/sec

Dimension Diagram:

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve 0

4V320(Grommet)

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve 1

4V320(Terminal)

Product Features:
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection
