| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V220-08 |
| Minimum Order Quantity: | 200 PCS |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Port Size: | In=Out=1/4'' Exhaust=1/8'' | Valve Type: | Double Solenoid 5 Port 2 Position |
|---|---|---|---|
| Voltage: | 220VAC 110VAC 24VDC 12VDC | Connector: | Terminal & Grommet |
| Working Pressure: | 0.15 To 0.8MPa(21-114psi) | Temperature: | -20 To +70℃ |
| Max. Frequency: | 5 Cycle/sec | Body Material: | Aluminum Alloy |
| Fluid: | Air (to Be Filtered By 40 μm Filter Element) | Application: | Automation |
| High Light: | 4V220-08 Pneumatic Solenoid Valve,1/4'' Pneumatic Solenoid Valve,AirTAC Type 4V220-08 |
||
4V220-08 1/4'' Double Coil 5/2 Way Air Pneumatic Solenoid Valve
Application:
The check valve allows compressed air to enter the gas tank from the compressor. When the compressor is closed, the compressed air is prevented from flowing in the opposite direction. When the pressure in the gas storage tank exceeds the allowable limit, the compressed air can be discharged; the directional control valve passes. The two ports of the cylinder are alternately pressurized and exhausted to control the direction of motion; the speed regulating valve can easily realize the stepless speed regulation of the actuator.The solenoid valve can be applied not only to pneumatic systems, but also to the same or similar applications in hydraulic systems and water pressure systems, such as low-power, non-oil-filled small electromagnetic reversing valves. Seals do not need to be supplied with oil. The gas does not pollute the environment and can be used in food, medicine, electronics and other industries.
Now, solenoid valve technology combined with control technology, computer technology, and electronic technology has been able to perform a variety of complex controls. For example, the solenoid valve can be applied in the field of intelligent control and applied in wireless control technology. Because the solenoid valve can be controlled by electromagnetic, it can interface well with various electronic systems, which is one of the main reasons for its wide application.Solenoid valves have been widely used in various fields of production. With the improvement of electromagnetic control technology and manufacturing processes, solenoid valves can achieve more sophisticated control, and play a role in realizing different pneumatic systems and hydraulic systems.
Technical Data:
|
Model
|
4V210-06
4V220-06
|
4V230C-06
4V230E-06
4V230P-06
|
4V210-08
4V220-08
|
4V230C-08
4V230E-08
4V230P-08
|
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
|||
|
Acting
|
Internal pilot or external pilot
|
|||
|
Port Size
|
In=Out=Exhaust=1/8''
|
In=Out=1/4'' Exhaust=1/8''
|
||
|
Orifice Size
|
25.00 mm2 (Cv=0.78)
|
18.00 mm2 (Cv=0.67)
|
30.00 mm2 (Cv=0.89)
|
18.00 mm2 (Cv=0.67)
|
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
5 port 2 position
|
5 port 3 position
|
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
|||
|
Proof Pressure
|
1.5MPa (215psi)
|
|||
|
Temperature ℃
|
-20~70
|
|||
|
Material of Body
|
Aluminum alloy
|
|||
|
Max. frequency
|
5 cycle/sec
|
3 cycle/sec
|
5 cycle/sec
|
3 cycle/sec
|
Dimension Diagram:
4V220(Grommet)
4V220(Terminal)
Product Features:
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
