| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | MP-C-011 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 set per month |
| Product Name: | MP-C-011 Solenoid Coil | Voltage: | 24VAC, 110VAC, 120VAC, 220VAC, 240VAC (50/60Hz) |
|---|---|---|---|
| Reference No: | 099257-009-D, 099257-016-D, 099257-005-D, 099257-008-D, 099257-001-D 099257-004G, 099257-014G, 099257-006G | Connection Type: | Flying Leads |
| Insulation Class: | F, H | Temperatrue Class: | T, B |
| Repair Solenoid Valve Model: | 29515, 29547, 29698, 18724, 18721, 17120, 17121 | Application: | Henny Penny Fryer |
| High Light: | Solenoid Valve Coil 220VAC,Henny Penny Solenoid Valve Coil,MP-C-011 Solenoid Coil |
||
Henny Penny Fryer Parts Solenoid Valve Coil MP-C-011 220VAC 240VAC
Working principle of solenoid valve coil:
When current flows through the solenoid coil, it generates a magnetic field inside the solenoid coil which attracts the armature towards the center of the solenoid using the same basic principles as ordinary electromagnets. Since the armature is drawn towards the center of the solenoid regardless of the polarity of the current, an opposing force is needed to return the armature into the starting position when the coil is not energized. This is achieved by using a spring mechanism. Under ideal conditions, in order to actuate the solenoid, the force generated by the solenoid must be larger than the combined forces of the spring, and the hydraulic pressure, as well as friction.
Dimension & Data of MP-C-011 Solenoid Coil:
|
Model
|
MP-C-011
|
|
Connection Type
|
Flying Leads
|
|
Voltage
|
24VAC, 110VAC, 120VAC, 220VAC, 240VAC (50/60Hz)
|
|
Insulation Class
|
H, F
|
|
Temperature Class
|
T, B
|
|
Model
|
BAPC216049003
|
|
Function
|
2/2 Way, Normally Closed
|
|
Tube Material
|
Stainless Steel
|
|
Shading Ring Material
|
Copper
|
|
Seat Type
|
Thread
|
|
Fitted Coil
|
MP-C-011
|
|
Application Example
|
Henny Penny Fryer
|
Multi-angle display of MP-C-011 solenoid coil:
MP-C-011 Coil surface parameter laser marking display:
Brando Factory Production Video of Solenoid Coils:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Echo
Tel: +8613454729544
